72
Specifying settings for mono and stereo mapping
(X.linkHD and X.linkSD)
You can choose to mute or enable each of the audio outputs from the X.linkHD or
X.linkSD breakout box when playing back mono and stereo tracks in your
sequence.
° To specify your mono/stereo mapping settings:
Choose Sequence > Sequence Settings and click the Playback
1
Settings
2
Click the Audio Output tab, then click the Mono/Stereo Mapping tab.
¦ Note
To mute the output for a particular channel, click its speaker button. For
3
example, to mute the analog output, click the speaker button under Analog .
To re-enable the channel, click the button again.
Under SDI , you can enable a maximum of four SDI audio pairs (two pairs
4
from any two groups). To enable an audio pair for a group that is presently
not available, you must mute both audio pairs from one of the currently
selected groups. Once an SDI channel becomes available, you can click its
button to enable the channel (the speaker icons will appear on the button).
Click OK to save your settings and return to the Sequence Settings dialog
5
box.
Chapter 7, Defining Your Adobe Premiere Pro Settings
button.
The AES/EBU channels are not available on X.linkSD.
