224

X.linkHD breakout box

General

Typical operating voltages and current
consumption
Voltage
Current
Total power consumption: 19 Watts

Video input signals

SD-SDI/HD-SDI
1394
Reference In
Appendix C, Matrox Axio Specifications
Video standards
Dimensions
+3.3 V
0 A
Signal Type Qty
NTSC, PAL, NTSC-EIAJ, 1080i/PsF, 720p
L 32.7 cm × W 8.9 cm × H 7.6 cm
(12.875" × 3.5" × 2.975")
+5 V +12 V
1.2 A 0.9 A
Voltage
1 Compliant with
SMPTE 259M/SMPTE 292M
1 200 mV
1 SD: 1.0 V
HD: 1.0 V
–12 V
0.18 A
Impedance
p-p
p-p
(tri-sync)
p-p
75 Ω
110 Ω
75 Ω
75 Ω
