Operating controls
Terminal Block.
01
»
»
»
»
»
»
CODING LED
02
DOOR CODE
03
DOOR STATUS LED
04
SET
button (Orange) is used during the installation phase together with the Open and MINUS (-) buttons
05
to set the door limit positions. The Set button is also used to re-initialize the Opener.
OPERATE
06
opener. The opener has to be initialised by the set button to make the OPERATE button operable.
FORCE MARGIN SET
07
margin can be adjusted manually using the Force Margin Set button (White). Holding the Force Margin Set
button and pressing PLUS (+) or MINUS (-) buttons will increase or decrease the amount of force. The Force
Margin Set should only be used if environmental factors (wind, etc.) affect the door's operation.
OPEN LIMIT LED
08
door is opening and remains steady on when the open limit position has been reached.
PLUS
(+) button (green) is used during installation to help set the open limit position. Pressing and holding
09
this button will move the door in the open direction, releasing stops the door.
NOTE: The safety obstruction detection is inoperable when the PLUS (+) button is used to move door.
CLOSE LIMIT LED
10
door is closing and remains steady on when the close limit position has been reached.
MINUS
(-) button (red) is used during installation to help set the close limit position. Pressing and holding
11
this button will move the door in the close direction. Movement stops when the button is released.
NOTE: The safety obstruction detection is inoperable when the CLOSE button is used to move door..
DATUM ADJUST SCREW
12
10A FUSE
13
PROG INPUT
14
control and receiver functions, accessing diagnostic tools, and activating special features and operating
modes.
15
JP1 SOLAR CONNECTOR
COURTESY LIGHT
16
GDO-11v1 SecuraLift ®
8
24V PWR is used to power photo electric beam.
PE (Input) for photo electric beam for safety.
PE (0v) is used to supply 0 volts to photo electric beam.
GND is used with OSC input or AUX out put
O/S/C INPUT is used for the connection of a wired switch (momentary contact). This switch
can then be used to open, stop or close the door. Install the wall switch in a location where
the switch is out of reach of children and the garage door is visible.
AUX (output) can be used to control alarm system .
(red) light fl ashes when a code is being stored or when a transmitter button is pressed.
BUTTON is used for storing or erasing transmitter buttons for door operation
(Yellow)
button (Yellow) is used during installation to test the open, stop and close cycles for the
Button: The obstruction force margin is set automatically during installation. The
(green) the LED is very helpful during installation. It illuminates and fl ashes when the
(red) the LED is very helpful during installation. It illuminates and fl ashes when the
is used during limits set up to indicate the mid point of the door's travel.
is used to connect the Automatic Technology Handheld Programmer "PG-3" for editing
onto this the shunt must be fi tted for solar operation.
15 watts 24 volts feston type globe is used for courtesy light
