- Page 1 GDO-11v1 SecuraLift ® Overhead Garage Door Opener Featuring TrioCode ™ Technology Part # 13246 (Manual v1.02)
- Page 2 Automatic Technology (Australia) Pty Ltd Garage Door Opener in accordance with these installation instructions.
-
Page 3: Table Of Contents
Default Settings & Specifi cations Coding Transmitters Parameters Door Door Status Indicators Vacation Mode Auxiliary Out Put Button functions Pet Mode Troubleshooting Guide Maintenance Record Courtesy Light Parts Listing Remotely Coding Transmitters Warranty Erasing Transmitter Codes GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 4: Important Safety Instructions
(P.E.) Beam. In most countries P.E. Beams are mandatory on all garage doors fi tted with automatic openers. For a small additional outlay Automatic Technology recommends that Photo Electric Beams be installed with the automatic opener ensuring additional safety and peace of mind. - Page 5 Install the (optional) wall switch or (optional) wall mounted transmitter in a location where the garage door is visible, but out of the reach of children at a height of at least 1.8 meters from the fl oor. GDO-11v1 SecuraLift ® Owner Installation Instructions...
-
Page 6: Features
Features Thank you for purchasing the Automatic Technology ® GDO-11v1 SecuraLift Overhead Garage Door Opener. Designed to suit sectional overhead and one piece tilt up doors, the components and materials used ensure this opener will provide years of smart, simple and secure operation. Listed... - Page 7 This allows for manual operation of the door. To re-engage the opener pull the string handle away from the door. GDO-11v1 SecuraLift ® Owner Installation Instructions...
-
Page 8: Operating Controls
10A FUSE PROG INPUT is used to connect the Automatic Technology Handheld Programmer “PG-3” for editing control and receiver functions, accessing diagnostic tools, and activating special features and operating modes. - Page 9 fi g GDO-11v1 SecuraLift ® Owner Installation Instructions...
-
Page 10: Kit Contents
Kit contents GDO-11v1 Multipiece C Rail And Accessory 1 x GDO-11v1 SecuraLift® Ero drive unit (Fig. 02) 1 x TrioCode™ Transmitter pack (Fig. 02) (Pack includes 1x four button keyring transmitter and 1x two button keyring transmitter with batteries) 2 x Door attachment arms (Fig. 02) fi... -
Page 11: Installation
Join to chain index with chain links ( supplied ) (Fig. 07). fi g Idler pulley Shuttle with hole side toward the door fi g GDO-11v1 SecuraLift ® Owner Installation Instructions... - Page 12 (Fig. 10). Continue to adjust adjust the tension hex bolt until a force of 8kg to 8.5 Kg is achieved. 9 teeth sprocket fi g Tension hex bolt fi g Centre of the track GDO-11v1 SecuraLift ® Owner Installation Instructions...
-
Page 13: C-Rail Attachment
Rail’s sprocket (Fig. 11). Fix the two track brackets with four screws supplied in accessory pack (Fig. 12). fi g Locate shaft into sprocket Mushroom Head Screw Taptite ‘S’ M4 x 8 Track bracket (x2) fi g GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 14: Determine Door Type
Step 4. fi g One piece door with track For a one-piece door without tracks (on springs) (Fig. 15) proceed with the installation from Step 8. Door fi g One piece door without track GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 15: Mounting On A Track Type Door
Connect the powerhead to the ceiling mounted perforated angle with M8x20mm screws and nuts. Strips should not extend more than 18mm below fi g centre of powerhead mounting holes. Go to Step 12 on page 17. GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 16: Mounting - Spring Loaded Door
Steel Rail The opener can be fastened to the roof by driving a bolt through the C-Rail into a structural timber support. The Shuttle Assembly bolt head’s height must not exceed 6mm (Fig. 23). GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 17: Mounting Door Bracket & Arms
If installing on a door with a bad wave action, lengthening the arm will assist in reducing this effect. IMPORTANT NOTE: Adjust the length of the cord so that its toggle is no more than 1.8m from fi g the ground. GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 18: Programming The Opener
Press and hold the MINUS (-) button for six (6) seconds until you hear three beeps and the CLOSE LIMIT LED starts to fl ash. Release the CLOSE button. Repeat Steps 14.1 to 14.4 to set new travel limit positions.. GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 19: Setting Travel Limits - Transmitter
Repeat Steps 15.1 and 15.3 to set new travel limit positions. » There is no need to re-code the transmitter (Step 15.2) upon resetting travel limits. The transmitter will still be stored in memory. GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 20: Safety Obstruction Forces
fi g countries P.E. Beams are mandatory on all garage doors fi tted with automatic openers. For a small additional outlay Automatic Technology recommends that Photo Electric Beams be installed with the automatic opener ensuring additional safety and peace of mind. -
Page 21: Adjusting Safety Obstruction Forces
(4) times (depending on the position of the door and the power up condition). A single beep will be heard once the process is complete. Test the force again as per Steps 16.1 and 16.2. GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 22: Coding Transmitters
Press one of the four buttons on the transmitter for two (2) seconds, pause for two (2) seconds, then press the same button again for two (2) second. Release the DOOR CODE button. Press the transmitter button to test. fi g GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 23: Pet Mode
(2) seconds, pause for two (2) seconds, then press the same button again for two (2) seconds. Release the DOOR CODE button. Press the transmitter button to test the courtesy light. fi g GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 24: Remotely Coding Transmitters
CODING LED will illuminate. fi g Release the DOOR CODE BUTTON. All stored codes will now be deleted. Confi rm this pressing buttons on any previously coded transmitters - the opener should not respond. GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 25: Auxiliary Out Put
(one) second. The maximum DC voltage must not exceed 35 volts DC. Maximum current must not exceed 80 ma.(Fig. 48). External device Alarm, Door opener etc. PE ( 0V ) fi g AUX OUT GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 26: Battery Back Up Installation
Connect mains power and allow the result of a residual charge in the batteries. batteries to charge. This may take 24 - 48 hours to reach maximum charge capacity. GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 27: Smartsolar™ Installation
Refi t the light diffuser and main cover. Step 24.4 - Re-setup and Test the Opener Setup travel limits and code transmitters as per the GDO-11v1 instruction manual. Press either the OPERATE button or use a transmitter to operate the opener. GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 28: Final Set Up
Press and hold the SET Button (Fig 56). Turn power on while holding the SET button. Continue to hold until all LEDs are off. » This will not erase transmitter codes stored in memory. fi g GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 29: Default Settings & Specifi Cations
NOTE: Intermittent operations may occur in areas which experience very strong winds. The strong wind puts extra pressure on the door and tracks which may in turn trigger the safety obstruction detection system intermittently. P.E Beams should be fi tted as added safety in case of entrapment. GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 30: Parameters
Deletes all transmitter storage memory are off SET & DOOR CODE (the power on) and hold until all Deletes all control parameters and transmitter LEDs are off storage memory. Re-initialises the Opener to re-calculate force margin GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 31: Troubleshooting Guide
In such an instance please contact your ATA dealer for an alternative frequency replacement kit. As this is not a warrantable situation but an environmental issue charges may apply for the changeover. GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 32: Maintenance Record
• NOTE: If the door does not operate smoothly, call your installer. Service Record Record any maintenance in the following table to assist in any warranty service. Date Service by Signature Invoice No. Amount GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 33: Parts Listing
Parts Listing GDO-11v1 SecuraLift ® Owner Installation Instructions... -
Page 34: Warranty
Trade Practices Act 1974 (Cwth). 2. Subject to all of the matters set out below, Automatic Technology Australia Pty Ltd (“ATA”) warrants: (a) overhead door opener drive units for twelve (12) months or 2500 cycles, whichever occurs fi rst; and (b) all components and accessories for twelve (12) months, from the date of purchase (specifi... - Page 35 GDO-11v1 SecuraLift ® Owner Installation Instructions...
- Page 36 ® are trademarks of Automatic Technology (Australia) Pty Ltd. No part of this document may be reproduced without prior permission. In an ongoing commitment to product quality we reserve the right to change specifi cation without notice. E&OE. Automatic Technololgy (Australia) Pty Ltd...
