Default Settings & Specifi cations
Factory default settings
Maximum motor run time
Courtesy light time
Obstruction force margin
Technical specifi cations
Power supply
Transformer rating
Standby power
Motor power
Motor type
Shuttle travel distance in the C-Rail
Maximum shuttle travel distance in the C-Rail
Maximum door opening:
(With 3160mm Standard track)
Minimum Clearance
(Bottom of C-Rail to highest point of door travel)
Short term peak force
Lift force
Nominal force
Receiver type
Receiver code storage capacity
Transmitter frequency
Coding type
Number of code combinations
Code generation
Transmitter battery
Courtesy light
Controller fuse
NOTE: Intermittent operations may occur in areas which experience very strong winds. The strong wind
puts extra pressure on the door and tracks which may in turn trigger the safety obstruction detection system
intermittently.
P.E Beams should be fi tted as added safety in case of entrapment.
Default Step
60 Secs. -
3 Mins.
10 Sec in battery back
up mode
0.5 Amp 0.1
230V - 240V AC 50Hz
72 VA
2.2 Watts
90 Watts
24V DC permanent magnet
3.1m approx (standard)
4m (with extended C-Rail)
Width: 5500mm (12m
Height: 2150mm
Weight: 80 kg
25mm
650N (65kg)
400N (40kg)
150N (15kg)
Multi-frequency FM Receiver
8 x 4 button transmitter codes
~= to 433.92 MHz
TrioCode™
Over 4.29 billion random codes
Non-linear encryption algorithm
CR 2032
Festoon style lamp 24 volts 15 watts
10A slow blow
Owner Installation Instructions
Maximum
-
2 Amp
2 )
