- Page 1 AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD GDO-2 SecuraLift ® GARAGE DOOR OPENER Warning: It is vital for the safety of persons to OWNERS COPY follow all instructions. Failure to comply with the installation instructions and the safety warnings may result in serious personal injury and/or Installation Instructions property and remote control opener damage.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Warnings............Product Features............Operating Controls............Package Contents............Tube/Pipe Assembly............ Determining Door Type..........Mounting The Opener - Track Type Door....Mounting The Opener - Spring Type Door....Mounting Brackets And Assembling Arms....Setting Limits Via Control Panel........ Setting Limits Via Transmitter........ -
Page 3: Safety Warnings
Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology Australia Pty Ltd Garage Door Opener. -
Page 4: Product Features
PRODUCT FEATURES Thank you for purchasing the ATA ISS (INTELLIGENT SAFETY VACATION MODE SecuraLift Automatic Garage Door OBSTRUCTION SYSTEM) A hand held transmitter can be ® Opener. This opener is designed to suit While the door is performing a close programmed to lock and unlock all sectional overhead and one piece tilt up cycle, should it hit an obstacle or be... -
Page 5: Operating Controls
OPERATING CONTROLS 1. LIGHT CODE button (white) is 8. SET button (yellow) is used during 13. P. E. SHUNT. The shunt has to be used for storing or erasing the the installation phase together with the removed when connecting a Photo transmitter button (code) you wish to Open and Close buttons to set the door Electric Beam. - Page 6 OPERATING CONTROLS LIGHT CODE BUTTON (WHITE) OPEN DRIVE BUTTON (GREEN) CODING LED (RED) OPEN LIMIT LED(GREEN) DOOR CODE BUTTON (BLUE) FORCE MARGIN SET BUTTON DOOR STATUS LED (YELLOW) P.E. SHUNT CLOSE DRIVE BUTTON (RED) PROG. INPUT CLOSE LIMIT LED (RED) O/S/C INPUT AUTO CLOSE BUTTON (WHITE) ENGAGE/DISENGAGEMENT CORD...
-
Page 7: Package Contents
PACKAGE CONTENTS ITEM QUANTITY GDO-2 SECURALIFT DRIVE UNIT ® SECURACODE KEY RING TRANSMITTER - PTX-4 ® EASY ACCESS TRANSMITTER - EAT-1 (Not available all models) WALL MOUNT BRACKET FOR PTX-4 BATTERY A23 12V ALKALINE TUBES TUBE INSERTS PIPE SUPPORT ASSEMBLY... -
Page 8: Tube/Pipe Assembly
TUBE/PIPE ASSEMBLY IMPORTANT SAFETY INSTRUCTIONS FOR FIG. 1 INSTALLATION Warning: Incorrect installation can lead to severe injury. Follow ALL installation instructions. CHECK OPERATION OF DOOR BEFORE BEGINNING THE INSTALLATION OF THE SECURALIFT AUTOMATIC OPENER CHECK THE ® SECOND CHAIN OPERATION OF THE DOOR. JOINT LINK The door must be well balanced and be in a reasonable operating condition. -
Page 9: Determining Door Type
DETERMINE THE DOOR TYPE Determine which type of garage door you have as illustrated FIG. 3 SECTIONAL DOOR WITH TRACK below. (Fig. 3 -5). For a sectional (panel) door on tracks (Fig. 3) proceed with the installation from Step 5. For a one piece door on tracks (Fig. -
Page 10: Mounting The Opener - Track Type Door
MOUNTING OPENER FOR TRACK TYPE DOOR STEP 5 FIG. 6 Open the door and find the highest point of travel of the top door panel. Using a level, transfer this height to the wall above the floor (Fig. 6) and mark a line 60mm above it. LEVEL LEVEL TRACK... -
Page 11: Mounting The Opener - Spring Type Door
MOUNTING OPENER FOR SPRING LOADED DOOR STEP 9 FIG. 10 Determine the centre of the door and mark this location on the CENTRE OF DOOR wall above and on top of the door. Then draw two (2) lines 21.5mm on each side of the door. (Fig. 10). WARNING;... -
Page 12: Mounting Brackets And Assembling Arms
MOUNTING DOOR BRACKET AND ARMS STEP 13 FIG. 14 The door bracket comes in two parts. The bottom plate with two mounting holes is used on its own for any one piece doors. The top plate is placed over the bottom plate and uses 4 mounting holes for extra strength. -
Page 13: Setting Limits Via Control Panel
SETTING LIMITS STEP 15 FIG. 18 SETTING TRAVEL LIMITS POSITIONS METHOD ONE: VIA THE CONTROL PANEL IMPORTANT NOTE: The O/S/C button will not function until the open and close limits positions are set. 15.1 SETTING LIMITS POSITIONS 1. Plug the drive unit power cord into mains power point and switch power on. -
Page 14: Setting Limits Via Transmitter
SETTING LIMITS STEP 16 FIG. 20 SETTING TRAVEL LIMIT POSITIONS INCH OPEN METHOD TWO: VIA THE TRANSMITTER BUTTON 1 IMPORTANT NOTE: The O/S/C button will not function BUTTON 2 until the open and close limits position are set. INCH CLOSE 16.1 SETTING LIMITS BUTTON 4 1. -
Page 15: Setting Obstruction Force Margin (Iss)
SETTING SAFETY OBSTRUCTION FORCE STEP 17 FIG. 22 SAFETY OBSTRUCTION TEST Please take care when testing the Safety Obstruction Force. Excessive force may cause SERIOUS PERSONAL INJURY and/or PROPERTY DAMAGE can result from failure to follow this warning. 17.1 TESTING CLOSE CYCLE 1. -
Page 16: Coding Transmitters
CODING TRANSMITTERS STEP 18 FIG. 24 SETTING TRANSMITTERS CODES Make sure to connect the battery to the transmitters. The memory in the openers receiver can store up to 23 different remote control transmitters. 18.1 STORING THE TRANSMITTERS CODE 1. Press and hold the Door Code button (Fig. 24). 2. - Page 17 CODING TRANSMITTERS STEP 19 FIG. 27 STORING TRANSMITTER(S) FROM A REMOTE LOCATION Using this method you don’t need to have access to the control panel on the Door Opener. However, you do need a transmitter that is pre coded to the controller’s receiver. IMPORTANT NOTE: The Door or Courtesy Light must be activated when the step below is performed.
-
Page 18: Connecting Photo Electric Beam
P.E. BEAM AND AUTO CLOSE 21. FITTING THE SAFETY PHOTO FIG. 29 ELECTRIC BEAM SENSOR (OPTIONAL) Locate the Photo Electric Beam (P.E.) normally closed contact type in a strategic location within doorway. We recommend 150mm above the floor level and as close as possible to the door opening, inside the garage. -
Page 19: Setting Courtesy Light Time
FINAL SET UP FIG. 31 23. SETTING OF COURTESY LIGHT TIME The preset courtesy light time on the door opener is 3 minutes. This time can be changed by the following: 1. Press in and hold both the Auto Close Time button and Force Margin Set button (Fig. -
Page 20: Door Status Indicators
PARAMETERS DOOR STATUS INDICATORS DOOR OPENER STATE OPEN LED CLOSE LED DOOR STATUS BEEPER GREEN LED YELLOW OPEN CLOSE OPENING FLASHING FLASHING CLOSING DOOR TRAVEL STOPPED FLASHING FLASHING DOOR OBSTRUCTED WHEN OPENING FLASHING BEEPS WHILE DOOR OBSTRUCTED WHEN CLOSING FLASHING DOOR IS MOVING ALTERNATING ALTERNATING... -
Page 21: Factory Default Settings
DEFAULT SETTINGS AND SPECIFICATIONS FACTORY DEFAULT SETTINGS DEFAULT STEP MAXIMUM MAXIMUM MOTOR RUN TIME 30 Secs. — — COURTESY LIGHT TIME 3 Mins. 10 Secs. 10 Mins. OBSTRUCTION FORCE MARGIN AUTO CLOSE TIME 0 Secs. 5 Secs. 4 Mins. TECHNICAL SPECIFICATIONS INPUT VOLTAGE: 230V - 240V AC 50Hz MOTOR TYPE:... -
Page 22: Trouble Shooting Guide
TROUBLE SHOOTING SYMPTOM POSSIBLE CAUSE REMEDY Switch on mains power. Door will not operate. Mains power not switched on. Remove obstruction. Door is obstructed. Unlock door or remove jam. Door is locked or motor jammed. Door requires service/repair by qualified Door tracks/hardware damaged. -
Page 23: Parts List
SPARE PARTS LIST WHEN ORDERING SPARE PARTS PLEASE QUOTE THE ORDER CODE NUMBER TO YOUR YOUR INSTALLER/DISTRIBUTOR... -
Page 24: Warranty
Trade Practices Act 1974 (Cth). 2. Subject to all of the matters set out below, Automatic Technology Australia Pty Ltd ("ATA") warrants: (a) swing and sliding gate opener drive units for twelve (12) months or 2500 cycles, whichever occurs first;...
