Summary of Contents for Automatic Technology GDO-10V3L2 Toro
- Page 1 GDO-10V3L2 Toro Roll Up Garage Door Opener Doc # 160033_02 Part # 13375 Released 25/05/15...
-
Page 2: Table Of Contents
Technology Australia Pty Ltd hereby further expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any person as a result whether directly or indirectly from failure to install the Automatic Technology Australia Pty Ltd Garage Door Opener in accordance with these installation instructions. -
Page 3: Important Safety Instructions
Disconnect the power cord from mains power before making any repairs or removing covers. Only experienced service personnel should remove covers from the opener. • If the power supply cord is damaged, it must be replaced by an Automatic Technology service agent or suitably qualified person. •... -
Page 4: Controller Input And Outputs
Lock Relay Output N/O, Com, Motor Connector N/C Contact 10 Amps Slow Blow Fuse Serial Interface Connector 24 Volts Ac In Connector 12 volts 6 Amp - Hr Batteries Position Sensor Connector Engage/Disengagement Handle Standby Battery Charger/Solar Connector GDO-10V3L2 Toro Owner Installation Instructions ™... -
Page 5: Operating Controls
0V Common Terminal For Control Inputs Console Close Button FIRE N/O , N/C Input Terminal GPI N/O Input Terminal OPN N/O , N/C Input Terminal STP N/O , N/C Input Terminal CLS N/O Input Terminal Owner Installation Instructions GDO-10V3L2 Toro ™... -
Page 6: Set Up Requirements
Items Required Dead Man Set Up Drive Unit, console Automated Set Up Drive Unit, console and transmitter Automated Set Up Drive Unit, console, transmitter and safety beams with Safety Beams (optional extra) Fig 4.1 GDO-10V3L2 Toro Owner Installation Instructions ™... -
Page 7: Pre-Installation Requirements
Warning: Incorrect installation can lead to severe injury. Follow ALL installation instructions. NOTE: Planetary chain equipment must be removed from the door prior to installation of GDO-10V3L2 Toro™. 5.1 Door Operation The door must be in good operating condition. The maximum effort to move the door up or down, from stationary, should not exceed 150 Newtons (15 kg force) at the bottom rail. -
Page 8: Installation
Ensure the internal gear is pushed in as far as possible (without interfering with the door curtain) and that all of the door drum’s wheel spokes are completely between the opener’s drive forks. GDO-10V3L2 Toro Owner Installation Instructions ™... -
Page 9: Installing The Wall Mounted Control Unit
If the closing force as measured on the bottom of the door is over 400N (40kg), a Safety Beam must be installed. The Safety Close mode can be turned off by changing the parameter in menu 6.1 (Section 16.1). NOTE: Fitting Safety Beams enables the Auto-Close feature to become active. Owner Installation Instructions GDO-10V3L2 Toro ™... -
Page 10: Setting Limits
Otherwise, the controller will be loaded with “Safety Close Mode.” See Section 13.1 for further details. h. Place cover back on logic console and affix with screws when unit setup is complete. GDO-10V3L2 Toro Owner Installation Instructions ™... -
Page 11: Code A Transmitter For Limit Setting
8. Setting Limits: Via Transmitter The GDO-10V3L2 Toro™ has the alternate ability to set travel Button 1 limits using a transmitter, allowing free movement around the (Inch Open) Button 2 garage to better assess the desired limit positions. In order to use a... -
Page 12: Coding Transmitter
Press SET to save the settings or STOP to abort without saving. 9.3 Returning To Main Screen Press STOP to return to the MAIN SCREEN and test the transmitter. NOTE: To edit the other settings, refer to transmitter edit procedure in Appendix F. GDO-10V3L2 Toro Owner Installation Instructions ™... -
Page 13: Remotely Coding Transmitters
Ped position, then Fig 11.2 the door will close. 11.3 Error Displays During the above procedure many error checks are performed. If an error is detected, a message will be displayed indicating the error. Owner Installation Instructions GDO-10V3L2 Toro ™... -
Page 14: Safety Obstruction Force Test
(depending on the position of the door and the power up condition). b. A single beep will be heard once the process is complete. c. Test the force again as per “Safety Obstruction Force Test” (Section 12.1 and 12.2). GDO-10V3L2 Toro Owner Installation Instructions ™... -
Page 15: Safety Close & Auto-Close Mode
Door. Details about the four Auto-Close configured to activate Safety Beam Auto-Close mode. modes follow. Automatic Technology strongly recommend using a Safety Beam for added safety. Menu 3.6 (Safety Beam) Pedestrian Auto-Close This mode is selected by entering a non-zero time for the Menu 3.1 Standard Auto Close... -
Page 16: Time Clock
Free Door Release the controls from the timer. the opener, then this status is displayed on This will temporarily disable the program. the LCD. The MAIN SCREEN and clock status Fig 14.5 screen flashes alternatively. GDO-10V3L2 Toro Owner Installation Instructions ™... -
Page 17: Day Light Saving Time Adjustment
Press OPEN to increase or CLOSE to decrease the time. LOCK e. Press SET to save the new time. f. Press the STOP button two times to exit and test the locks operation. Owner Installation Instructions GDO-10V3L2 Toro ™... -
Page 18: Battery Replacement
Check your local Refer to the Automatic Technology website for information on where regulations for appropriate disposal of to recycle batteries in Australia. the batteries. -
Page 19: Specifications
3. If the Safety Beam are not installed then the controller will automatically goes into “Safety Close“ mode. Limited number of features are available in this mode please refer to Section 13.1. Owner Installation Instructions GDO-10V3L2 Toro ™... -
Page 20: Troubleshooting
Safety Beam is obstructed. Remove obstruction from path of Safety Beams. Door obstructed when closing. Remove obstruction. Auto-Close time not set. Set Auto-Close times (Section 13.3). Auto-Close mode not set Set Auto-Close mode. (Section 13.2) GDO-10V3L2 Toro Owner Installation Instructions ™... -
Page 21: Maintenance
20.5 Service Indicator warranty may be void. To keep your door running well, it is As a reminder the GDO-10V3L2 Toro™ has a built in recommended that your door be serviced by an experienced maintenance counter. This counter has a factory default... -
Page 22: Appendix
Time the lock is activated for prior to closing Menu 5 - Motor Settings OPEN SPEED VOLTAGE ~12.0 Volts Appendix C Sets the full speed motor voltage GDO-10V3L2 Toro Owner Installation Instructions ™ CLOSE SPEED VOLTAGE ~12.0 Volts Appendix C... - Page 23 SETTINGS 17.3 Menu 8 - Diagnostics TEST INPUTS - Controls input display status Inactive Appendix D TEST TRANSMITTERS (TX’ERS) Appendix D DISPLAY HISTORY Appendix D MEMORY USAGE Appendix D Owner Installation Instructions GDO-10V3L2 Toro ™ SERVICE COUNTER 60,000 Appendix D...
-
Page 24: B - Viewing & Editing Logic Console Parameters
Saves new to return to the sub menu. Press STOP again to return to Displays “Load value Default?” screen, the MAIN SCREEN. giving option of Exits back to View loading default Mode value Decrease value GDO-10V3L2 Toro Owner Installation Instructions ™... -
Page 25: C - Control Board Adjustments
The STP input is normally configured for N/O operation. This parameter allows its operation to be changed to N/C. Menu 6.11 FIRE Input Polarity The FIRE input is normally configured for N/O operation. This parameter allows its operation to be changed to N/C. Owner Installation Instructions GDO-10V3L2 Toro ™... - Page 26 This parameter enables activity report outputs. Contact Automatic Technology for more details. 6.15 Activity Report ID This parameter sets the ID of the controller that is sent with the activity report. Contact Automatic Technology for more details. 6.16 Vacation Mode Vacation Mode can be turned on or off using this parameter.
-
Page 27: D - Diagnostic Tools
This tool displays the number of transmitter store locations used and the number free (Fig. D.6). Close Complete Used = BB SMITH EVENT # 64 Free = OSC PED LGT>VAC PRESS Fig D.4 Fig D.5 Fig D.6 Owner Installation Instructions GDO-10V3L2 Toro ™... -
Page 28: E - Memory Tools
This option will clear the door control memory and reload the factory set defaults for parameters such as the lock time, light time, Auto-Close times etc. It will also clear the travel limits. Menu 9.2 Clear Transmitters (Tx’ers) This option will clear the transmitter storage memory. GDO-10V3L2 Toro Owner Installation Instructions ™... -
Page 29: F- Transmitter Editing
NOTE: If all button functions are set to OFF, when SET is pressed, the opener will prompt to confirm if the transmitter is to be deleted. Press SET to delete or STOP to continue editing. Owner Installation Instructions GDO-10V3L2 Toro ™... - Page 30 The second line of the display shows a list of available characters with the F.8). current value indicated at the cursor position (Fig. PRESS 14 I B B SMITH 56789 AB CDEFGHIJ Fig F.7 PRESS 12345 OSC PED LGT VAC Fig F.8 PRESS GDO-10V3L2 Toro Owner Installation Instructions ™...
-
Page 31: G - Transmitter Management
G - Transmitter Management MENU 1 Code Transmitter Transmitter Listing Facility The GDO-10V3L2 Toro™ provides a transmitter listing facility which enables PRESS Fig G.1 the user to find a transmitter location within the memory. Once located a stored transmitter can be replaced, deleted, edited, copied or, if the location PRESS is empty, a new transmitter can be coded. -
Page 32: Warranty And Exclusion Of Liability
22. Warranty and Exclusion of Liability 1. This Warranty is given by Automatic Technology (Australia) Pty Ltd (ABN 11 (i) door surface area and/or weight exceeding 28m2 and 270kg respectively; 007 125 368) (ATA), 6-8 Fiveways Boulevard, Keysborough 3173, 1300 133 944, (j) the door used with the Product not being in safe working order and condition;...
