Operating Controls

08 11
03
fi g
07
12
06
Logic Console
Terminal Block ( From Left To Right )
06
V+ Three Wire P.E. Beams " + " Supply
IN3 Three Wire P.E. Beams Trigger Input
V- Common For Two Wire EasyBeam™ and
Three Wire P.E. Beams
IN2 Two Wire EasyBeam™ Input
AUX OUT Receiver's Auxiliary Output
FIRE Input Terminal (N/O or N/C)
GPI N/O Input Terminal (N/O)
OPN Input Terminal (N/O or N/C)
STP Input Terminal (N/O or N/C)
CLS Input Terminal (N/O)
SWP Input Terminal (N/O)
COM Terminal For Inputs
09
10
13
14
15
11
12
14
07
15
Manual Console
Programmer PG-3 Input
07
Console Previous Button
08
Liquid Crystal Display
09
Console Next Button
10
Console Open Button
11
Console Stop Button
12
Console Set Button
13
Console Close Button
14
RJ45 Connector
15
Owner Installation Instructions Axess® Pro Series 3100
