- Page 1 GDO-10V2L2 Roll Up Garage Door Opener Featuring TrioCode ™ Technology Technical Document Installation Manual 1.00 27 Jan 2012 English Part # 13288 (Manual) INSTALLATION INSTRUCTIONS | OWNERS COPY...
- Page 2 Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology Australia Pty Ltd Garage Door Opener.
-
Page 3: Table Of Contents
GDO-10V2L2 Toro ™ Roll Up Garage Door Opener Important Safety Instructions Features Controller Input And Output Operating Controls Package Contents Pre-installation Requirements Installation Safety Beam Installation Programming The Opener Menu Structure Viewing And Editing Parameters Setting Limits Setting Limits: Via Transmitter Safety Obstruction Force Adjusting Safety Obstruction Forces 20 Coding Transmitters... -
Page 4: Important Safety Instructions
CAUTION: If your garage has no pedestrian entrance door, an emergency access device should be installed. This accessory allows manual operation of the garage door from outside in case of power failure. Automatic Technology strongly recommends Safety Beams are installed with the automatic opener ensuring additional safety and peace of mind. - Page 5 Important Safety Instructions The garage door must be well balanced. Sticking or binding doors must be repaired by a qualifi ed garage door installer prior to installation of the opener. Frequently examine the installation for signs of wear, damage or imbalance. DO NOT use if repair or adjustment is needed since a fault in the installation or an incorrectly balanced door may cause injury.
-
Page 6: Features
Features Thank you for purchasing the Automatic Technology Toro™ Automatic Garage Door Opener. Designed by our renowned engineers to suit roll up doors, the Toro™ will provide years of smart, simple & secure convenience to your home. Operation To open or close the door simply press the open or close button on the wall control unit, a button on a coded TrioCode™... - Page 7 SmartSolar™ Compatibility (Optional) The opener can be fi tted with a SmartSolar™ kit (Part Number 60142) for operation where mains power access is not available. NOTE: If the door is the only entrance to the garage, a keyed cable release should be fi tted external to the garage. Vacation Mode A hand held transmitter can be programmed to lock and unlock all other transmitters that have been programmed into the openers’...
-
Page 8: Controller Input And Output
Controller Input And Outputs fi g Light Relay Output N/O, Com, N/C Contact Standby Battery Shunt Lock Relay Output N/O, Com, N/C Contact Motor Connector Serial Interface Connector 10 Amps Slow Blow Fuse 12 volts 6 Amp - Hr Batteries 24 Volts Ac In Connector Engage/Disengagement Handle Position Sensor Connector... -
Page 9: Operating Controls
Operating Controls fi g Terminal Block ( From Left To Right ) Programmer PG-3 Input Console Previous Button AUX OUT Receiver’s Auxiliary Output Liquid Crystal Display V+ Accessory Supply Console Next Button SB3 Third Safety Beam Input Console Open Button SB2 Second Safety Beam Input Console Stop Button SB1 First Safety Beam Input... -
Page 10: Package Contents
Package Contents GDO-10V2L2 Toro™ Drive Unit Wall Control Unit L2 Network Cable Accessory Guide Pack Fork Extension Pack TrioCode™ Keyring Transmitters Installation Manual Locking Bar Covers fi g GDO-10V2L2 Toro ™ Owner Installation Instructions... -
Page 11: Pre-Installation Requirements
Pre-Installation Requirements IMPORTANT SAFETY INSTRUCTIONS FOR INSTALLATION Warning: Incorrect installation can lead to severe injury. Follow ALL installation instructions. NOTE: Planetary chain equipment must be removed from the door prior to installation of GDO-10V2L2. Door Operation The door must be in good operating condition. The maximum effort to move the door up or down, from stationary, should not exceed 150 Newtons (15 kg force) at the bottom rail. -
Page 12: Installation
Installation Sideroom For Left Hand Side Installation IMPORTANT NOTE - Do not lock your door The minimum sideroom required from the edge of with the locking bars after installing the the door curtain is 127 mm to the inside of the door opener. - Page 13 Installation Step 3 - Mounting The Opener If the internal gear does not rotate freely, switch the opener to manual by pulling the disengagement handle down (there will be a click), so the ring gear can be rotated by hand. Slide the opener over the door axle and into the drum of the door (Fig.
-
Page 14: Safety Beam Installation
Repeat steps a and b to assemble the Safety Beam receiver. Locate the Safety Beam in a strategic location in the doorway. Automatic Technology recommend that the sensor is placed 100mm above the fl oor level and as close as possible to the door opening. Connect as per the wiring diagram (Fig. -
Page 15: Programming The Opener
Programming The Opener Menu structure NOTES NOTE: System will automatically return to the main screen 1. Press PREV/NEXT buttons move to Left/Right. after 30 secs if a menu screen is displayed and no buttons 2. Press OPEN/CLOSE buttons to change setting. are pressed. -
Page 16: Viewing And Editing Parameters
Viewing and Editing Parameters This section illustrates how to locate, view and View Mode (No cursor) adjust parameters. Parameter name Parameter number in sub menu Locating parameters 5: Close Lock Refer to MENU STRUCTURE on Page 15 or the preceding Parameter Time (sec) 0.5 section for CONTROL BOARD ADJUSTMENTS. -
Page 17: Setting Limits
Setting Limits Step 6.1 - Setting Travel Limits WARNING! Use caution when operating the manual release with the door open since it may fall rapidly due to weak or broken springs, or an improperly balanced door. CAUTION! Do not disengage the opener to manual operation with children, persons or fi... -
Page 18: Setting Limits: Via Transmitter
Setting Limits: Via Transmitter The GDO-10V2L2 has the alternate ability to set travel limits using the transmitter, allowing free movement around the garage to better assess the desired limit MENU 1 positions. In order to use a transmitter, it must fi rst have Code Transmitter at least one of its buttons coded to the door controller. -
Page 19: Safety Obstruction Force
Safety Obstruction Force Safety Obstruction Force Test WARNING! Take care when testing or adjusting the Safety Obstruction Force. Excessive force may cause SERIOUS PERSONAL INJURY and/ or PROPERTY DAMAGE. Step 8.1 - Testing Close Cycle Press the OPEN button to open the door. Place a piece of timber approximately 40mm high on the fl... -
Page 20: Adjusting Safety Obstruction Forces
Adjusting Safety Obstruction Force Safety Obstruction Force The Safety Obstruction Force is calculated automatically during setup. Adjusting this is normally only necessitated Menu 2 by environmental conditions such as windy or dusty areas, Current Trips and areas with extreme temperature changes. WARNING: The Safety Beam must be used if fi... -
Page 21: Coding Transmitters
Coding Transmitter The GDO-10V2L2 can store up to fi ve hundred and eleven (511) transmitters in its memory. Each transmitter ID/SN display indicator I.D label/Serial number can be allocated an alpha-numeric ID label up to eleven (11) characters in length and each button can Store number fi... -
Page 22: Transmitter Editing
Transmitter Editing Editing Transmitter Settings MENU 1 Code Transmitter Display Transmitter Record Using one of the methods below, display the required fi g transmitters details. PR E S S Navigating To “Edit Transmitter” Menu 1. Press NEXT to navigate to Menu 1 (Fig. 29) . 2. - Page 23 Transmitter Editing (cont.) Editing The Store Location 14 I [No Name] This feature is only available when coding the fi rst OSC PED LGT VAC button of a new transmitter. 1. Press NEXT or PREV to move the cursor over Store fi...
-
Page 24: Transmitter Management
Transmitter Management The GDO-10V2L2 provides a transmitter listing facility MENU 1 which enables the user to fi nd a transmitter location Code Transmitter within the memory. Once located a stored transmitter can be replaced, deleted, edited, copied or, if the PRESS fi... - Page 25 Transmitter Management Code Operation (location used) MENU 1.2 If the code operation is selected for a location that Delete already contains a transmitter, then the BASIC CODE TRANSMITTER PROCEDURE will be initiated and the new transmitter will replace the existing one. Note that the button functions and name of the existing fi...
-
Page 26: Remotely Coding Transmitters
Remotely Coding Transmitters If a transmitter is already coded into the opener, additional transmitters can be coded without being in direct contact with the opener’s control panel. PRESS Existing NOTE: Only the function of the existing transmitter transmitter button can be assigned to new transmitter. Please fi... -
Page 27: Setting Pedestrian Position
Setting Pedestrian Position Pedestrian Access Position After completing the limit setup procedure the MENU 10.3 Pedestrian Access position is automatically set to Set Pedestrian a position which is approximately in the middle of the door travel. The position can be manually set by following the Setting Pedestrian Position procedure. - Page 28 Standard Operating Modes Motor Speed Control - SOFT START/SOFT GPI (General Purpose Input) General purpose input can be confi gured as OSC,Ped STOP or day light saving setup. The GPI input terminal is The motor’s speed is microprocessor controlled, activated with the N/O switch. ramping up speed as the door starts to move, and ramping down as it approaches the travel When GPI Selected As OSC :...
-
Page 29: Control Board Adjustments
Standard Operating Modes Vacation Mode Vacation Mode blocks all but one designated remote control transmitter from activating the GDO-10V2L2 opener. The mode is activated by pressing a transmitter button with the VAC function assigned until the console displays that Vacation Mode is enabled (approx. 5 secs). When activated all the transmitter buttons will be ignored. To turn Vacation Mode off press a transmitter button with the VAC function assigned. - Page 30 Control Board Adjustments Menu 6.3 First (SB1) Safety Beam Response Mode The Safety Beams input can be confi gured to respond in one of three modes. Reverses Close Cycles In this mode, the Safety Beam input has no effect when opening but will cause the door to reverse if activated when closing.
- Page 31 This parameter enables activity report outputs. Contact Automatic Technology for more details. 6.15 Activity Report ID This parameter sets the ID of the controller that is sent with the activity report. Contact Automatic Technology for more details. 6.16 Vacation Mode Vacation Mode can be turned on or off using this parameter.
- Page 32 Control Board Adjustments 6.20 Fault, Auto Reset When selected, the controller will reset any fault automatically. 6.21 LED Low Power Mode When LED low power mode is selected, the controller will turn the LED power off to save the power. 6.22 Console OSC Buttons Console can be locked out by selecting console OSC buttons OFF.
- Page 33 Control Board Adjustments Parameter Default Step Unit Menu Safety Close Mode Safety Open Mode Safety Beam Input Response Mode Sets the S.B OPN & CLS stop CLS to 6.3-5 response mode. Options are OPEN and CLOSE CLS to stop reverse cycles stop, Close cycles stop or Close cycle reverse CLS to reverse SB REVERSE TIME...
-
Page 34: Time Clock
Time Clock The opener provides a programmable time clock which MENU 8.1 can be used to control the GDO-10V2L2 on a timed Set Time/Date basis at various times of the week. This section details the time clock operation and confi guration. fi... - Page 35 Time Clock The selectable functions available are: When GPI Input Is Confi gured As PED: The activation of the GPI input or by pressing a RX = Off transmitter button with PED function assigned From the time when the program with RX = OFF is will open the door partially to allow pedestrian activated, all the transmitters will be disabled.
-
Page 36: Diagnostic Tools
Diagnostic Tools The controller provides several diagnostic tools from MENU 9 within the Diagnostics Menu (Menu 8). This section Diagnostics details the function of each tool and its use. fi g Navigating To Diagnostics Menu 1. Press PREV to navigate to Menu 8 (Fig. 54). PRESS 2. - Page 37 Diagnostic Tools Menu 8.5 Service Counter Service Counter The opener provides a periodic service counter which (Cycles) 60000 can be set to expire after a number of drive cycles. When expired, the opener will beep three times at fi g the beginning of each drive cycle and a message will be displayed on the MAIN SCREEN (Fig.
-
Page 38: Memory Tools
Memory Tools Menu 9.0 Memory Tools The Memory Tools accessed from within Menu 9 are used to clear the transmitters codes from the openers memory and clear the controller’s memory. Once selected, the PREV or NEXT buttons can be used to view the Memory Tool options. -
Page 39: Lock
Accessories Installation Step 16 Lock Step 16.1 - Fitting Solenoid Or Magnetic Locks Install the lock mechanism on the door as per the manufacturers instructions. See Fig. 63 for the wiring LIGHT diagram. fi g Menu 4. Light/Lock Times SUITABLE Lock output can be programmed for both hold POWER SUPPLY... -
Page 40: Auto-Close Mode
Auto-Close Mode Step 17 - Setting Up Auto-Close Mode NOTE: the Auto-Close function is not available unless Safety Beam is installed. Auto-Close mode is a function that automatically closes the door a preset time after the Safety Beam recognise that a vehicle has left the garage. The Auto-Close timer only starts after the Safety Beam path is broken and the Auto-Close timer has been set. -
Page 41: Wall Transmitter Installation
Parameter Default Step Unit Menu No. STD AUTO-CLOSE TIME 60.0 Sets and enables the standard Auto-Close time S.B AUTO-CLOSE TIME Sets and enables the S.B 60.0 triggered Auto-Close time PEDESTRIAN AUTO-CLOSE TIME Sets and 60.0 enables the Pedestrian Auto-Close time S.B PEDESTRIAN AUTO-CLOSE TIME Sets and 60.0 enables the PE Pedestrian Auto-Close time... -
Page 42: Smartsolar™ Installation
SmartSolar™ Installation Warning: Do not connect the batteries until after Step 18.2 30 Watt Solar Kit Part Number 60142 is suitable for GDO10-V2 Step 19.1 - Mount The Charger Board Unplug the drive unit from mains power. Disengage motor using manual release cord. Remove the bottom cover by pressing in from sides and sliding downward. -
Page 43: Replacing Backup Batteries
Replacing Backup Batteries Step 20 Replacing Backup Batteries Unplug the drive unit from mains power. Disengage motor using manual release cord. Remove the bottom cover by pressing in from sides and sliding downward. Remove the two screws and slide upward the top cover upwards to remove it. -
Page 44: Specifi Cations
Specifi cations Technical Specifi cations Power supply 230V - 240Va.c. 50Hz Standby power 2.6 Watts Geared Motor power 150 Watts Motor type 24Vd.c. Permanent Magnet Maximum door opening: Height: 5500mm Width: 5100mm Weight: 270kg Opener Limits Travel 5.5 turns of Door Drum Wheel Maximum Rated Load 500N Nominal Load... -
Page 45: Troubleshooting
Troubleshooting Symptom Possible cause Remedy Door will not operate Mains power not switched on. Switch on mains power. Door is obstructed. Remove obstruction. Door is locked or motor jammed. Unlock door or remove jam. Door tracks/hardware damaged. Door requires service/repair by qualifi... -
Page 46: Maintenance
Maintenance Yearly Whilst your opener does not require any periodic Automatic Technology suggests you contact your garage maintenance, the door that it is fi tted to does. door professional to perform an annual door service. Your garage door is a large, heavy, moving object... -
Page 47: Spare Parts
Spare Parts fi g ™ Owner Installation Instructions GDO-10V2L2 Toro... -
Page 48: Warranty
Warranty and Exclusion of Liability 1. This Warranty is given by Automatic Technology (Australia) (h) the operating force exceeding 15kg* (150 Newton) when moving Pty Ltd (ABN 11 007 125 368) (ATA), 6-8 Fiveways Boulevard, the door manually to the open or closed position;... - Page 49 © January 2012 Automatic Technology (Australia) Pty Ltd. All rights reserved. TrioCode™ , Toro™ and SmartSolar trademarks of Automatic Technology (Australia) Pty Ltd. No part of this document may be reproduced without prior permission. In an ongoing commitment to product quality we reserve the right to change specifi cation without notice. E&OE.
