Operating controls
Terminal Block.
01
24V PWR is used to power devices such as:
»
»
»
SET
button (orange) is used during the installation phase together with the Open and MINUS (-) buttons to
02
set the door limit positions. The Set button is also used to re-initialize the Opener.
LIGHT CODE
03
to switch the courtesy light on the opener on or off.
CODING LED
04
OPERATE
05
opener. The opener has to be initialised by the Reset button to make the O/S/C button operable.
DOOR CODE
06
DOOR STATUS LED
07
MINUS
(-) button (red) is used during installation to help set the close limit position. Pressing and holding
08
this button will move the door in the close direction. Movement stops when the button is released.
NOTE: The safety obstruction detection is inoperable when the CLOSE button is used to move door..
PLUS
(+) button (green) is used during installation to help set the open limit position. Pressing and holding
09
this button will move the door in the open direction, releasing stops the door.
NOTE: The safety obstruction detection is inoperable when the PLUS (+) button is used to move door.
CLOSE LIMIT LED
10
door is closing and remains steady on when the close limit position has been reached.
OPEN LIMIT LED
11
door is opening and remains steady on when the open limit position has been reached.
AUTO CLOSE TIME
12
CLOSE TIME button and then pressing the PLUS (+) button the time is increased. Each press will increase
the time by 1 second. Pressing the MINUS (-) button will decrease the time.
FORCE MARGIN SET
13
margin can be adjusted manually using the Force Margin Set button (White). Holding the Force Margin Set
button and pressing PLUS (+) or MINUS (-) buttons will increase or decrease the amount of force. The Force
Margin Set should only be used if environmental factors (wind, etc.) affect the door's operation.
JP1 SOLAR CONNECTOR
14
PROG INPUT
15
control and receiver functions, accessing diagnostic tools, and activating special features and operating
modes.
16
SBY-3 CONNECTOR
GDO-9v3 SecuraLift ®
8
PE (Input) for photo electric beam for safety and auto-close function.
LGT (Input) allow hard wired external trigger for the opener's courtesy light.
O/S/C INPUT is used for the connection of a wired switch (momentary contact). This switch
can then be used to open, stop or close the door. Install the wall switch in a location where
the switch is out of reach of children and the garage door is visible.
button (white) is used for storing or erasing the transmitter button (code) you wish to use
(red) light fl ashes when a code is being stored or when a transmitter button is pressed.
button (Yellow) is used during installation to test the open, stop and close cycles for the
BUTTON (blue) is used for storing or erasing transmitter buttons for door operation
(Yellow)
(red) the LED is very helpful during installation. It illuminates and fl ashes when the
(green) the LED is very helpful during installation. It illuminates and fl ashes when the
button (White) is used to adjust the auto close time. While holding in the AUTO
Button: The obstruction force margin is set automatically during installation. The
onto this the shunt must be fi tted for solar operation.
is used to connect the Automatic Technology Handheld Programmer "PG-3" for editing
is used to connect both Battery Back Up Kits and SmartSolar™ kits.
Owner Installation Instructions
