Final Set Up

fi g 54
fi g 55
fi g 56
GDO-11v1 SecuraLift ®
28
Step 25 - Setting the Pet Mode position
The default Pet Mode height can be changed as follows:
When activated, Pet Mode drives the door to the preset
position from either above or below. Pet Mode's active
status is indicated by both the OPEN and CLOSE LIMIT
LEDs being illuminated. If a Pet Mode button is pressed
while the door is moving the door will stop. If a Pet
Mode button is pressed when the door is in the Pet
position, then the door will close.
Step 26 - Installing the Wall Mounted
Transmitter (Optional)
Step 27 - Reset all Factory Defaults
a.
b.
c.
Owner Installation Instructions
a. Make sure the door is closed, then press and hold
the PLUS(+) button for six (6) seconds (Fig. 54),
until you hear three beeps and the OPEN and
CLOSE LEDs fl ash rapidly.
b. Press the OPEN or CLOSE button to move the
door to the desired pet mode open position.
c. Press the SET button to record the new position.
a. Remove the faceplate from the transmitter.
b. Affi x the baseplate in a convenient wall location
(Fig 55) that is the door is visible from this
location. but out of the reach of children at a
height of at least 1.8 meters from the fl oor.
c. Replace the faceplate.
d. To code the transmitter, see Steps 10.1 through
10.4 on page 19.
Turn power to opener off.
Press and hold the SET Button (Fig 56).
Turn power on while holding the SET button.
Continue to hold until all LEDs are off.
» This will not erase transmitter codes
stored in memory.
