Knockdown C-Rail Assembly
fi g
08
9 teeth sprocket
fi g
09
Tension hex bolt
fi g
10
GDO-11v1 SecuraLift ®
12
Centre of the track
Owner Installation Instructions
Note: Use the 12 teeth sprocket with Gdo-11v1 opener.
h.
Engage the shuttle with the chain index and move
shuttle assembly to the centre of track. Make sure
the chain is engaged into the sprocket and also
wrapped around the centre of the pulley.
i.
Use a spring scale to measure required force to pull
the shuttle, adjust 1/2" tension hex bolt (Fig. 09) to
tension the chain.
j.
Move the shuttle back to the centre of the track to
re-test the force with spring scale (Fig. 10).
k.
Continue to adjust adjust the tension hex bolt until a
force of 8kg to 8.5 Kg is achieved.
