AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD
GDO-2 SecuraLift
®
GARAGE DOOR OPENER
Warning: It is vital for the safety of persons to
OWNERS COPY
follow all instructions. Failure to comply with the
installation instructions and the safety warnings
may result in serious personal injury and/or
Installation Instructions
property and remote control opener damage.
Please save these instructions for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GDO-2 SecuraLife and is the answer not in the manual?

Questions and answers

Related Manuals for Automatic Technology GDO-2 SecuraLife

Summary of Contents for Automatic Technology GDO-2 SecuraLife

  • Page 1 AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD GDO-2 SecuraLift ® GARAGE DOOR OPENER Warning: It is vital for the safety of persons to OWNERS COPY follow all instructions. Failure to comply with the installation instructions and the safety warnings may result in serious personal injury and/or Installation Instructions property and remote control opener damage.

  • Page 2: Important Safety Instructions

    Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology Australia Pty Ltd Garage Door Opener.

  • Page 3: Product Features

    PRODUCT FEATURES Your SecuraLift Automatic Garage To store any code simply press and hold OPEN AND CLOSE DRIVE ® Door Opener has many features which the Door Code button on the opener and BUTTONS you will appreciate. The components press the transmitter button twice. Each Developed by ATA to and materials used in this Automatic...

  • Page 4: Operating Controls

    OPERATING CONTROLS 1. LIGHT CODE button (White) is 6. RESET button is used to initialise 11. CLOSE LIMIT ADJUST used for storing or erasing the and set the door/opener operating SCREW (Red) is used to adjust the transmitter button (code) you wish to parameters, including cycle times and close limit stop position.
  • Page 5 OPERATING CONTROLS LIGHT CODE BUTTON (WHITE) OPEN LIMIT LED(GREEN) DOOR CODE BUTTON (BLUE) FORCE MARGIN SET BUTTON CLOSE DRIVE BUTTON (RED) CLOSE LIMIT ADJUST SCREW (RED) CLOSE LIMIT LED (RED) OPEN LIMIT ADJUST SCREW (GREEN) AUTO CLOSE BUTTON (WHITE) P.E. SHUNT SET BUTTON (YELLOW) O/S/C INPUT O/S/C BUTTON (YELLOW)

  • Page 6: Package Contents

    PACKAGE CONTENTS ITEM QUANTITY GDO-2 SECURALIFT DRIVE UNIT ® SECURACODE KEY RING TRANSMITTER - PTX-4 ® WALL MOUNT BRACKET FOR PTX-4 BATTERY A23 12V ALKALINE TUBES TUBE INSERTS PIPE SUPPORT ASSEMBLY CHAIN SHUTTLE/TROLLEY ASSEMBLY DOOR ATTACHMENT ARMS ACCESSORY PACK INSTALLATION MANUAL...

  • Page 7: Tube/Pipe Assembly

    TUBE/PIPE ASSEMBLY IMPORTANT SAFETY INSTRUCTIONS FOR FIG. 1 INSTALLATION Warning: Incorrect installation can lead to severe injury. Follow ALL installation instructions. CHECK OPERATION OF DOOR BEFORE BEGINNING THE INSTALLATION OF THE SECURALIFT AUTOMATIC OPENER CHECK THE ® OPERATION OF THE DOOR. The door must be well balanced and be in a reasonable operating condition.

  • Page 8: Determine The Door Type

    DETERMINE THE DOOR TYPE Determine which type of garage door you have as illustrated FIG. 5 below. (Fig. 5 - 7). For a sectional (panel) door on tracks (Fig. 5) proceed with the installation from Step 5. For a one piece door on tracks (Fig. 6) proceed with the installation from Step 5.
  • Page 9 MOUNTING OPENER FOR TRACK TYPE DOOR STEP 5 FIG. 8 Open the door and find the highest point of travel of the top door panel. Using a level, transfer this height to the wall above the door (Fig. 8) and mark a line 60mm above it. Determine the centre point on the wall above and on top of the door.
  • Page 10 MOUNTING OPENER FOR SPRING LOADED DOOR STEP 9 FIG. 12 Determine the centre of the door and mark this location on the wall above and on top of the door. Then draw two (2) lines 21.5mm on each side of the centre point. (Fig. 12). WARNING: MAKE SURE CONCRETE, BRICK WALL OR TIMBER LINTELS ARE SOLID AND SOUND SO AS TO FORM A SECURE MOUNTING PLATFORM.
  • Page 11 MOUNTING DOOR BRACKET AND ARMS STEP 12 FIG. 15 With the centre point of the door located, mark a line through the centre of the wall bracket onto the header wall (above the door). Using the bracket as a template mark a minimum of two holes and drill with appropriate size bit.

  • Page 12: Setting Limits

    SETTING LIMITS STEP 15 FIG. 18 SETTING TRAVEL LIMIT POSITIONS IMPORTANT NOTE: The O/S/C button will not function until the open and close limit positions are set. 15.1 SETTING LIMIT POSITIONS 1. Plug the drive unit power cord into mains power point and switch power on.

  • Page 13: Setting Safety Obstruction Force

    SETTING SAFETY OBSTRUCTION FORCE STEP 16 - SETTING OPEN AND CLOSE FIG. 20 SAFETY OBSTRUCTION FORCE The safety obstruction force is calculated automatically and set in the memory of the SecuraLift . This applies to both the Open ® and Close Force.. WARNING: When step 16.1 is initiated the garage door will do a full open and close cycle automatically.

  • Page 14: Coding Transmitters

    CODING TRANSMITTERS STEP 17 - STORING TRANSMITTER CODES FIG. 22 PRESS AND Make sure to connect the battery to the transmitters. The HOLD DOOR CODE memory in the openers receiver can store up to 27 different BUTTON remote control transmitters. 17.1 STORING TRANSMITTER CODE 1.
  • Page 15 CODING TRANSMITTERS STEP 19 - SETTING THE TRANSMITTER TO FIG. 25 OPERATE THE COURTESY LIGHT The transmitter can be programmed to operate the courtesy light on the door opener. 1. Press and hold Light Code button (Fig. 25). 2. Press the button on the transmitter you would like to use to switch on the light for two seconds 3.
  • Page 16 P.E. BEAM AND AUTO CLOSE STEP 21 - FITTING THE SAFETY PHOTO FIG. 28 ELECTRIC BEAM SENSOR (OPTIONAL) Locate the Photo Electric Beam (P.E.) normally closed contact type in a strategic location within doorway. We recommend 150mm above the floor level and as close as possible to the door opening, inside the garage.

  • Page 17: Door Status Indicators

    PARAMETERS DOOR STATUS INDICATORS GREEN YELLOW DOOR COURTESY DOOR OPENER STATE BEEPER OPEN LED CLOSE LED STATUS LED LIGHT OPEN CLOSE FLASHING OPENING FLASHING CLOSING DOOR TRAVEL STOPPED FLASHING FLASHING DOOR OBSTRUCTED WHEN FLASHING BEEPS ON & OFF OPENING DOOR OBSTRUCTED WHEN FLASHING BEEPS ON &...

  • Page 18: Troubleshooting

    TROUBLE SHOOTING SYMPTOM POSSIBLE CAUSE REMEDY Switch on mains power. Door will not operate. Mains power not switched on. Remove obstruction. Door is obstructed. Unlock door or remove jam. Door is locked or motor jammed. Door requires service/repair by qualified Door tracks/hardware damaged.

  • Page 19: Spare Parts List

    SPARE PARTS LIST WHEN ORDERING SPARE PARTS PLEASE QUOTE THE ORDER CODE NUMBER TO YOUR YOUR INSTALLER/DISTRIBUTOR...

  • Page 20: Warranty And Exclusion Of Liability

    WARRANTY AND EXCLUSION OF LIABILITY Subject to all of the matter set out below, Automatic Technology Australia Pty Ltd (“ATA”) warrants for twenty four (24) months from the date of purchase (specified in the receipt sales docket) that the Garage Door Opener System contained in the accompanying packaging (the “Product”) is free of any defects in material and workmanship rendering it unmerchantable.
