Reference
Information
This section contains reference or supplemental information. Topics in this section include:

Mounting

Tabletop Mounting

Attach the provided rubber feet to the bottom four corners of the enclosure.

Rack Mounting

The scalers can be mounted into racks with the pre-installed rack ears (see
for rack mounted devices
and use the provided screws to attach the device to the rack shelf.
Figure 58.
Mounting
Downloading Updated Firmware
on page 76). To install the device, install a rack shelf to the rack
1U Universal Rack Shelf
Front false
faceplate
uses 2
screws.
Use 2 mounting holes on
opposite corners.
Half Rack Shelf Mounting
IN1604 DTP and IN1604 HD Scalers • Reference Information
1/2 Rack Width Front False
Faceplate
(2) 4-40 x 3/16"
Screws
UL Guidelines
75
