Configuration
Software
The Extron Product Configuration Software (PCS) offers another way to control the scalers
via USB connection in addition to the SIS commands.
This section describes the software installation and communication (see the IN1604 Series
Product Configuration Software help file for additional control information). Topics in this
section include:
•
•
•
•
The graphical interface includes the same functions as those on the device front panel with
additional features that are available only through the software.
The control software is compatible with Microsoft Windows operating systems. The software
program is available on the Extron website.

Installing the Software

Figure 20.
Installing the Software
Starting the Software
Using the Software
Configuration Pages
PCS Download from the Extron Website
IN1604 DTP and IN1604 HD Scalers • Configuration Software 47
