User Presets Submenu

Figure 10.
The User Presets submenu allows the current picture control settings for the selected input
to be saved, a user preset to be recalled, or a user preset to be erased. User presets can be
saved and recalled later on another input, allowing them to also be used as aspect ratio or
discrete size and center shortcuts. There are 16 user presets available per input. Press the
Input Selection buttons to select an input.
NOTE: If a saved preset is not named, "User Preset XX" is assigned.
From the Save, Recall, or Clear submenu item, press the Navigation buttons to select the
desired preset to either save picture control settings, recall previously saved picture control
settings, or reset a preset.
User presets save the following settings:
• Brightness and contrast
Color and tint
•
• Detail
• Image size and position
• Preset name
NOTE: To save and recall input presets, use SIS commands (see
on page 38) or the Configuration Software (see
page 70).
User Presets Submenu
IN1604 DTP and IN1604 HD Scalers • Operation
Preset Commands
Preset Management Page on
16
