Reset Device

This option opens a dialog box to confirm the resetting of device settings.
From the drop-down menu, select
Device
opens.
Figure 28. Reset Device Dialog Box
The reset changes all device settings to the factory defaults. It is the same as the
E }
SIS command (see
ZXXX
To reset the connected device, click the
without making any changes, click the
Backup and Restore
This option saves current configurations and restores saved configurations.
From the drop-down menu, click
Device
and Restore dialog box opens.
Figure 29. Backup and Restore Dialog Box
To save the current configuration settings to an external file:
1. In the Backup panel, click the
2. Navigate to the desired save location on the host device and click the
window closes.
3. Click the button to save the configuration to an external file on the host device.
Backup
4.
Click the button to close the System Backup and Restore window.
Close
To restore a saved configuration settings file:
1. In the Restore panel, click the
2. Navigate to the save location of the saved file and click the
window closes.
NOTE: Valid configuration files have a .extz file extension.
3. Click the button to apply the saved configuration settings.
Restore
4. Click the button to close the System Backup and Restore window.
Close
IN1604 DTP and IN1604 HD Scalers • Configuration Software
Reset Device...
Reset SIS commands on page 45).
button. To exit the Reset Device dialog box
Reset
button.
Cancel
Backup and Restore...
button. The Save As window opens.
Browse
button. The Open window opens.
Browse
. The Reset Device dialog box
. The System Backup
button. The
Save
button. The Open
Open
53
