Reference
Information
Mounting the SW USB Series Switcher
The SW USB Series switcher can be set on a table, mounted on a rack shelf, or mounted
under a desk, podium, or table.
Tabletop Use
Four adhesive rubber feet are included with the SW USB switcher. For tabletop use, attach
one foot at each corner on the bottom of the unit, and place the switcher in the desired
location.
Rack Mounting
UL rack mounting guidelines
The following Underwriters Laboratories (UL) guidelines pertain to the safe installation of the
equipment in a rack.
1.
2.
3.
4.
5.
Rack mounting procedure
To rack mount the SW USB, you can use one of the Extron 19-inch rack shelf mounting
options (go to
1.
2.
Elevated operating ambient temperature — If the equipment is installed in a closed
or multi-unit rack assembly, the operating ambient temperature of the rack environment
may be greater than room ambient temperature. Therefore, install the equipment in
an environment compatible with the maximum ambient temperature (TMA = +122 °F,
+50 °C) specified by Extron.
Reduced air flow — Install the equipment in a rack so that the amount of air flow
required for safe operation of the equipment is not compromised.
Mechanical loading — When mounting the equipment in the rack, ensure that uneven
mechanical loading does not cause a hazardous condition.
Circuit overloading — When connecting the equipment to the supply circuit, consider
the effect that circuit overloading might have on overcurrent protection and supply
wiring. Consider equipment nameplate ratings when addressing this concern.
Reliable earthing (grounding) — Maintain reliable grounding of rack-mounted
equipment. Pay particular attention to supply connections other than direct connections
to the branch circuit (for example, use of power strips).
www.extron.com
If feet were previously attached to the bottom of the switcher, remove them.
Mount the SW USB Series switcher on the rack shelf, using two 4-40 x 3/16 inch
screws in opposite (diagonal) corners to secure the unit to the shelf.
for part numbers).
