Input presets
There are 16 presets that are global to all inputs. The presets contain all of the settings for
an input when used with an upstream matrix switcher. Input presets save signal type, signal
sampling, and picture control settings.
To save an input preset:
1. From the Input Presets list (see
2. Click the
Save Preset
on it, the Presets dialog box opens. Click the
data and save the new settings. Click the
To rename a preset:
1. In the Input Preset Name column, double-click an
2. Change the name as desired.
3.
Press the <Enter> key to save the new name.
To recall an input preset:
1. From the Input Presets list (
2. Click the
Recall Preset
3. Click the button to recall the preset. Click the
Recall
Image Settings page.
To clear a preset:
1. From the Input Presets list (
2. Click the button (
Clear
3. Click the button to erase saved data. Click the
Clear
Image Settings page.

User Presets

There are 16 user presets per input to save picture control settings only.
To save a user preset:
1. From the User Presets list (
2.
Click the
Save Preset
on it, the Presets dialog box opens. Click the
data and save the new settings. Click the
To rename a preset:
1. In the User Preset Name column, double-click a
2. Change the name as desired.
3. Press the <Enter> key to save the new name.
To recall a user preset:
1. From the User Presets list (
2. Click the
Recall Preset
3. Click the button to recall the preset. Click the
Recall
Image Settings page.
To clear a preset:
1.
From the User Presets list (
2. Click the button (
Clear
3. Click the button to erase saved data. Click the
Clear
Image Settings page.
