5.11

Replacing the System Battery

The battery specifications for the Sun Ultra 20 M2 Workstation are shown in
TABLE 5-1
TABLE 5-1
Specification
Voltage
Type
Perform this procedure to remove and replace the system battery.
Caution – If you remove the system battery, you could erase all system-specific
information saved in the CMOS.
1. Perform the steps listed in
the Left Side Access Panel" on page
2. Gently lay the system on its right side on a stable, nonslip surface.
3. Pinch the battery latch together (squeezing away from the battery) until the
battery pops out of the motherboard socket (see
.
Battery Specifications
Value
3 VDC
CR 2032
Section 5.2.2, "Powering Off the System and Removing
5-3.
FIGURE 5-21
Chapter 5 Maintaining the Workstation
).
5-33
