9. Fasten the retaining screw into place. Torque the screws to 8- to 9-inch pounds.
10. Close the system by performing the steps in
Instructions" on page
Note – The onboard ATI graphics controller automatically stops working when you
install a graphics card into the PCI-E x16 slot (PCI-E slot 0). Therefore, a monitor
connected to the onboard DB15 VGA graphics connector will not provide any
output.
5.10

Removing and Installing PCI Cards

This section describes removing and installing standard PCI cards.
To remove and replace PCI-E cards, see
E Card" on page
5.10.1

Removing a PCI Card

This procedure describes how to remove a typical PCI card (including a host bus
adapter). PCI cards might vary in the way in they are installed in the system.
1. Perform the steps listed in
the Left Side Access Panel" on page
2. Gently lay the system on its right side on a stable, nonslip surface.
3. Remove any cables connected to the card.
4. Unscrew the PCI card retainer screw (see
5-5.
5-25.
Section 5.2.2, "Powering Off the System and Removing
5-3.
Section 5.3.1, "Postinstallation
Section 5.9, "Removing and Installing a PCI-
).
FIGURE 5-19
Chapter 5 Maintaining the Workstation 5-29
