7.2.10

Input Name Configuration

The name of any audio input source may be edited to reflect the actual use of the input. This is for reference
only, and it is shown in input related menu options.
In order to modify the input name proceed as follows.
1. Select Configuration System Router Inputs Mic/Line.
2. Scroll the Mic/Line input list and select the required input:
[I/P #01 – MIC/LINE 01]
Default value: input 1
Possible inputs: 01 to 04 for VAR4
01 to 12 for VAR12
01 to 20 for VAR20
Note: The input name is shown on the right side of the display. The input name above is the Mic/Line
input 1 default name, however this may have been changed according to each site's
configuration.
3. The configured Mic/Line type is displayed.
The input type may be changed, as described in Section
4. Press the SELECT key to display the next sub-menu.
5. Move to, and select the Name menu item, which is shown in different positions for different input types
as follows:
'Paging Microphone' and 'Zoned Fire Microphone'
Buttons Audio
'Single Button Microphone'
PTT Audio Ctrl [Name]
'Fire Microphone' and 'Miscellaneous Input'
Audio Ctrl [Name]
'Network Channel'
Audio [Name]
6. Edit the audio input name as required using the arrow keys or the rotary encoder.
[MIC/LINE nn ]
Default name: 'MIC/LINE nn', where nn is the input number
Possible value: alphanumeric string of up to 12 characters
Note: The DEFAULT key may be used to clear the entire text string to all blank, for speedier input.
7. Save the changes by pressing the SELECT key, or cancel by pressing the BACK key.
VAR4 / VAR12 / VAR20 - Operation Manual
Ctrl [Name]
Is sue: 03 complete, approved
Page 93 of 308
"7.1 Mic/Line Input Type Configuration".
