DVA Input Name Configuration

The name of any DVA input may be edited to reflect the actual use of the input, as described in the following
steps. This is for reference only, and is shown in DVA or input related menu options.
1. Select Configuration System Router Inputs DVA.
2. Scroll the DVA input list until the required DVA is displayed:
[EVAC 01]
Default value: DVA input 1
Possible DVAs: VAR4:
VAR12: EVAC 01 to EVAC 04 (inputs 1 to 4, long DVA)
VAR20: EVAC 01 to EVAC 06 (inputs 1 to 6, long DVA)
Note: The DVA input names given above are the default names, however these may be changed
according to each site's configuration.
3. Move to, and select the Name menu item:
Pri Class Gain
4. Edit the DVA input name as required using the arrow keys or the rotary encoder.
[EVAC nn ]
[TEST nn ]
Long DVA default name:
Short DVA default name:
Possible value:
Note: The DEFAULT key may be used to clear the entire text string to all blank, for speedier input.
5. Save the changes by pressing the SELECT key, or cancel by pressing the BACK key.
VAR4 / VAR12 / VAR20 - Operation Manual
EVAC 01 to EVAC 02 (inputs 1 to 2, long DVA)
TEST 01 to TEST 02 (inputs 3 to 4, short DVA)
TEST 01 to TEST 04 (inputs 5 to 8, short DVA)
TEST 01 to TEST 06 (inputs 6 to 12, short DVA)
O/pGains [Name]
'EVAC nn', where nn is the DVA number
'TEST nn', where nn is the DVA number
alphanumeric string of up to 12 characters
