14.2.1

Configuring the Zone Selection for a Routing Contact

Once a contact is configured for 'Routing', it is necessary to define the route or routes that it controls, by
associating an input to each available output, as described in the following steps.
1. Select Configuration System Router Control Contacts.
2. Move to, and scroll the contact list until the required contact is displayed in the left field:
[Contact#nn] Routing
Default value:
Contact numbers: 01 to 22 for VAR4
Where contacts:
3. Press the SELECT key to display the routing configuration menu.
4. Move to, and select the Zoning menu item:
[Zoning] Control
5. Move to, and scroll the output list until the required output is displayed in the left field:
[OUTPUT 01] Not-Conf
Default value: output 1 name
Outputs: 4 output for VAR4
12 output for VAR12
20 output for VAR20
Note: The output given above is the output 1 default name, however this may have been changed
according to each site's configuration.
6. Move to, and scroll the right field list until the required input is displayed:
OUTPUT 01 [Not-Conf]
•
[Not-Conf]
No route associated with the output.
•
[MIC/LINE 01]
The output is routed to this particular input.
Default value: 'Not-Conf'
Inputs: VAR4:
VAR12: Local inputs: 12 Mic/Line inputs + 8 DVAs + 1 music + Mute + Test Tone
VAR20: Local inputs: 20 Mic/Line inputs + 12 DVAs + 1 music + Mute + Test Tone
VAR4 / VAR12 / VAR20 - Operation Manual
Not-Surv
'Contact#01'
01 to 42 for VAR12
01 to 62 for VAR20
00 to 10 are analogue
11 to 62 are opto-isolated
Clear-all
Local inputs: 4 Mic/Line inputs + 4 DVAs + 1 music + Mute + Test Tone
Network inputs: 8 Mic/Line inputs + 4 DVAs + 1 music + Mute + Test Tone
Network inputs: 8 Mic/Line inputs + 4 DVAs + 1 music + Mute + Test Tone
Is sue: 03 complete, approved
Page 199 of 308
