7.3.4.4

Configuring a Button as an All-Call Button

The button function is 'select all zones'. When the button is pressed, all outputs, which have been configured
as being affected by any zone selection buttons on the microphone, are selected for broadcast from the
microphone, i.e. the button press has the same effect as if all zone selection buttons on the microphone
have been pressed. Pressing a zone selection button will remove the zones associated to this button from
the selection. Any button may be configured as an All-Call button.
The 'Select' and 'Busy' LEDs will illuminate in the same manner as if all the individual configured buttons
have been selected.
The 'Select' LED on an All-Call button is an OR function of the individual button 'Select' LEDs, i.e. it will flash
if any of the individual button LEDs flash, and steady on if an access is made to any of the zones. The 'Busy'
LED only illuminates on an All-Call button if all corresponding zone-selects have their 'Busy' LED illuminated,
i.e. at least one output in each zone of the zones is busy.
In order to configure a microphone button as an 'All-Call' button proceed as follows.
1. Select Configuration System Router Inputs Mic/Line.
2. Scroll the Mic/Line input list and select the required input:
[I/P #01 – MIC/LINE 01]
Default value: input 1
Possible inputs: 01 to 04 for VAR4
01 to 12 for VAR12
01 to 20 for VAR20
Note: The input name is shown on the right side of the display. The input name above is the Mic/Line
input 1 default name, however this may have been changed according to each site's
configuration.
3. The configured Mic/Line type is displayed.
The input type may be changed, as described in Section
4. Press the SELECT key to display the next sub-menu.
5. Move to, and select the Buttons menu item.
[Buttons] Audio Ctrl
Note: The 'Buttons' menu item is only available for Paging and Zoned Fire Microphones.
6. Move to, and select the Zoning menu item.
PTT [Zoning] Switches
7. Move to, and scroll the button list until the required button is displayed in the left field:
[Button #01] Not-Conf
Default value: 'Button #01'
Button numbers: 01 to 30
VAR4 / VAR12 / VAR20 - Operation Manual
Name
Cough
Security
Is sue: 03 complete, approved
Page 130 of 308
"7.1 Mic/Line Input Type Configuration".
