5.1.3.5

Network Channel Fade Up and Down Time Configuration

Ensure that the fade up/down times are set to their default setting of 00, as described in the following steps.
1. Select Configuration System Router Inputs Mic/Line.
2. Scroll the Mic/Line input list and select the Network Channel input:
[I/P #01 – MIC/LINE 01]
Default value: input 1
Possible inputs: 01, 03, and 04 can be programmed as Network Channel.
Note: The input name is shown on the right side of the display. The input name above is the Mic/Line
input 1 default name, however this may have been changed according to each site's
configuration.
3. The configured Mic/Line type is displayed.
[Network Channel]
4. Press the SELECT key to display the next sub-menu.
5. Move to, and select the Audio menu item.
[Audio] Name
6. Move to, and select the Fade menu item.
Surv EQ [Fade] Chime
7. Move to, and scroll the fade up times until '00' is displayed in the left field:
[Up=00] Down=00
8. Move to, and scroll the fade down times until '00' is displayed in the right field:
Up=00 [Down=00]
9. Save the changes by pressing the SELECT key, or cancel by pressing the BACK key.
