6.2

Viewing Configured Mainframes

6.2.1

Verbose View

The verbose view provides a mainframe's software version, as well as each amplifier's software version
number, power rating, and surveillance mode.
In order to view the details of an amplifier mainframe proceed as follows.
1. Select Configuration System View Verbose.
2. The configured mainframes are displayed:
[Frame02 v1.2] Slot1 v23.4 100W Standby
Note: If no mainframe is configured, then a warning message will be displayed.
If the software version is available, then is shown as in the above example, else 'V?.?' is
displayed.
'Standby': identifies a standby amplifier
'Single':
'Dual':
'Loop':
Pressing the DEFAULT key will display the Slot 1 configuration.
3. Scroll the mainframe list (left field) to view another mainframe configuration, or scroll the slot field (right
field) to view a different slot configuration within the currently selected mainframe:
Frame02 v1.2 [Slot1 v23.4 100W Standby]
4. Return to the parent menu by pressing the SELECT or BACK keys.
VAR4 / VAR12 / VAR20 - Operation Manual
identifies a single circuit surveillance mode
identifies a dual circuit surveillance mode
identifies a loop return surveillance mode
