Polycom KIRK Wireless Server 8000 Configuration Guide
10
To Change Communication Settings using the Edit button
From the Startup window, click the Change Communications
1
Configuration button. There is an automatic delay of 6 seconds that allows
you to click the button before the program starts. In the Communications
Configuration window, press the Edit button.
Right-click the cell with the information that you want to change, and click
2
Change.
Figure 3-4 Change Communication Configurations
In the Communications Configuration window, click the tab that is
3
named after the preferred type of connection.You have the following
options:
Type
Null Modem Cable
Telnet
Modem
Offline
On the Null Modem tab, enter a name for the connection in the Name
4
field, and then in the COM Port list, select the COM port to which the
modem has been installed, and then click OK.
On the Telnet tab, type the relevant IP Address and Port, and then click
5
OK. The Kirk Wireless Server OAM program window appears.
On the Modem tab, enter a name for the connection in the Name field, and
6
then in the COM Port list, select the COM port to which the modem has
been installed. The PBX Prefix, Phone Number, and Extension fields are
optional. The Wait/Pause field is filled in with a comma by default. Select
Pulse dialing, if you prefer this to DTMF dialing.
Table 3-3 Connection Types
Definition
Use this to connect directly to a PC.
Use this for remote connection via LAN.
Use this to connect via modem.
Use this to view the OAM program without
being connected.
Downloading the OAM Program
