NEC MultiSync FP1350 Service Manual page 94

TIMING NAME 21 VESA1280*1024@75Hz
Pixel Clock 135.000[MHz]
H.Frequency 79.976[kHz]
V.Frequency 75.025[Hz]
H.Tortal Time 1688 [dots] 12.504 [us]
H.Addr Time 1280 [dots]
H.Blank Time 408 [dots]
H.Front Porch 16 [dots]
H.Sync Time 144 [dots]
H.Back Porch 248 [dots]
V.Tortal Time 1066 [lines] 13.329 [ms]
V.Addr Time 1024 [lines] 12.804 [ms]
V.Blank Time 42 [lines] 0.525 [ms]
V.Front Porch 1 [lines] 0.013 [ms]
V.Sync Time 3 [lines] 0.038 [ms]
V.Back Porch 38 [lines] 0.475 [ms]
Scan Type Non-interlaced
H.Sync Polarity Positive
V.Sync Polarity Positive
Separate
TIMING NAME 26 H.HOLD2(110K)
Pixel Clock 237.600[MHz]
H.Frequency 110.000[kHz]
V.Frequency 160.000[Hz]
H.Tortal Time 2160 [dots]
H.Addr Time 1600 [dots]
H.Blank Time 560 [dots]
H.Front Porch 64 [dots]
H.Sync Time 192 [dots]
H.Back Porch 309 [dots]
V.Tortal Time 687 [lines] 6.250 [ms]
V.Addr Time 660 [lines] 6.000 [ms]
V.Blank Time 27 [lines] 0.250 [ms]
V.Front Porch 1 [lines] 0.013 [ms]
V.Sync Time 4 [lines] 0.038 [ms]
V.Back Porch 22 [lines] 0.200 [ms]
Scan Type Non-interlaced
H.Sync Polarity Positive
V.Sync Polarity Positive
Separate
22 VESA1600*1200@75Hz
202.500[MHz]
93.750[kHz]
75.000[Hz]
2160 [dots] 10.667 [us]
9.481 [us] 1600 [dots] 7.901 [us]
3.022 [us] 560 [dots] 2.765 [us]
0.119 [us] 64 [dots] 0.316 [us]
1.067 [us] 192 [dots] 0.948 [us]
1.837 [us] 304 [dots] 1.501 [us]
1250 [lines] 13.333 [ms]
1200 [lines] 12.800 [ms]
50 [lines] 0.533 [ms]
1 [lines] 0.011 [ms]
3 [lines] 0.032 [ms]
46 [lines] 0.491 [ms]
Non-interlaced
Positive
Positive
Separate
27 H.HOLD2(115K)
142.140[MHz]
115.000[kHz]
160.000[Hz]
9.091 [us] 1236 [dots] 8.695 [us]
6.734 [us] 900 [dots] 6.332 [us]
2.357 [us] 336 [dots] 2.364 [us]
0.269 [us] 68 [dots] 0.478 [us]
0.808 [us] 100 [dots] 0.704 [us]
1.280 [us] 168 [dots] 1.182 [us]
718 [lines] 6.250 [ms]
690 [lines] 6.000 [ms]
28 [lines] 0.250 [ms]
1 [lines] 0.013 [ms]
4 [lines] 0.038 [ms]
23 [lines] 0.200 [ms]
Non-interlaced
Positive
Positive
Separate
23 VESA1600*1200@85Hz 24 VESA1920*1440@75Hz
229.500[MHz]
106.250[kHz]
85.000[Hz]
2160 [dots] 9.412 [us] 2640 [dots]
1600 [dots] 6.972 [us] 1920 [dots]
560 [dots] 2.440 [us] 720 [dots]
64 [dots] 0.279 [us] 144 [dots]
192 [dots] 0.837 [us] 224 [dots]
304 [dots] 1.325 [us] 352 [dots]
1250 [lines] 11.765 [ms] 1500 [lines]
1200 [lines] 11.294 [ms] 1440 [lines]
50 [lines] 0.471 [ms] 60 [lines]
1 [lines] 0.009 [ms] 1 [lines]
3 [lines] 0.028 [ms] 3 [lines]
46 [lines] 0.433 [ms] 56 [lines]
Non-interlaced
Positive
Positive
Separate
28 V.MAX
84.500[MHz]
65.000[kHz]
80.65[Hz]
1300 [dots] 15.38 [us] 1328 [dots]
1024 [dots] 12.12 [us] 1024 [dots]
276 [dots] 3.26 [us] 288 [dots]
24 [dots] 0.28 [us] 16 [dots]
92 [dots] 1.09 [us] 96 [dots]
160 [dots] 1.89 [us] 176 [dots]
806 [lines] 12.4 [ms] 800 [lines]
596 [lines] 9.169 [ms] 788 [lines]
210 [lines] 3.231 [ms] 13 [lines]
89 [lines] 1.343 [ms] 0 [lines]
6 [lines] 0.092 [ms] 3 [lines]
115 [lines] 1.796 [ms] 9 [lines]
Non-interlaced
Negative
Negative
Separate
5-53
25 H.HOLD1
297.000[MHz]
112.500[kHz]
75.000[Hz]
8.889 [us] 900 [dots]
6.465 [us] 720 [dots]
2.424 [us] 180 [dots]
0.485 [us] 18 [dots]
0.754 [us] 108 [dots]
1.185 [us] 54 [dots]
13.333 [ms] 564 [lines]
12.800 [ms] 428 [lines]
0.533 [ms] 136 [lines]
0.009 [ms] 52 [lines]
0.027 [ms] 2 [lines]
0.498 [ms] 82 [lines]
Non-interlaced Non-interlaced
Negative Positive
Positive Positive
Separate Composit
29 V.RASTER 30 EDID
78.750[MHz]
60.023[kHz]
75.029[Hz]
16.66 [us] 900 [dots]
13.003 [us] 720 [dots]
33.657 [us] 180 [dots]
0.203 [us] 18 [dots]
1.219 [us] 108 [dots]
2.235 [us] 54 [dots]
13.328 [ms] 749 [lines]
13.128 [ms] 685 [lines]
0.217 [ms] 64 [lines]
0 [ms] 14 [lines]
0.05 [ms] 3 [lines]
0.150 [ms] 47 [lines]
Non-interlaced Non-interlaced
Positive Negative
Positive Negative
Separate Separate
27.900[MHz]
31.000[kHz]
54.963[Hz]
32.260 [us]
25.810 [us]
6.450 [us]
0.640 [us]
3.870 [us]
1.940 [us]
18.194 [ms]
13.807 [ms]
4.387 [ms]
1.677 [ms]
0.065 [ms]
2.645 [ms]
28.322[MHz]
31.463[kHz]
42.01[Hz]
31.777 [us]
25.422 [us]
6.36 [us]
0.636 [us]
3.813 [us]
1.907 [us]
23.8 [ms]
21.767 [ms]
2.034 [ms]
0.445 [ms]
0.095 [ms]
1.494 [ms]
