NEC MultiSync FP1350 Service Manual page 72

b. H. SIZE(MAX) adjustment
b-1. Select "Size / Position" while menu B is displayed, and push "RETURN" key.
b-2. Input a signal displayed on the screen. (If signal is not displayed on the screen, use a signal
indicated horizontal maximum size adjustment section in the service manual.)
b-3. As following menu will appear on monitor screen, select "83: H_MAX" and push "RETURN" key.
1:VGA350
2:VGA400
3:VGA480
4:800*600(60)
5:MAC2(640*480)
8:VESA640*480(75)
9:XGA
10:VESA800*600(75)
12:MAC2(832*624)
13:1024*768(70)
15: 1024*768(75)
16:1280*1024(60)
17:MAC_1152
18:1280*1024(70)
20:1280*1024(75)
Meaning of each item in this menu is as follow:
From "1" to "35" : Adjust monitor on each signal
"85"
"87"
23:98_640(70)
27:640*480(85)
28:1600*1200(85)
29:800*600(85)
30:1024*768(85)
32:1600*1200(75)
33:VESA350(85)
34:VESA400(85)
80:TOTAL1(1024*768(75))
83:H_MAX
84:H_MAX2
85:V SIZE(MAX)
87:END
: Adjust a vertical maximum size
: Size / Position adjustment is ended
FP1350-1
SIZE/POSITION ADJUSTMENT
Select No.
No. ?
(Menu D)
5-31
