R G B Color Control
Color Presets 1 through 5 selects the desired color setting. The bar is replaced by the color setting
choice from 1 to 5. Each color setting is adjusted at the factory to the stated Kelvin. If a setting is
adjusted, the name of the setting will change from Kelvin to Custom.
Red, Green, Blue : NEC's AccuColor Control System decreases or increases the monitor's red, green,
or blue color guns depending upon which is selected. The change in color will appear on screen and
the direction (decrease or increase) will be shown by the bars.
Geometry Controls
The Geometry controls allow you to adjust the curvature or angle of the sides of your display.
IN/OUT (pincushion): Decreases or increases the curvature of the sides either inward or outward.
LEFT/RIGHT (pincushion balance): Decreases or increases the curvature of the sides either to the
left or right.
TILT (parallelogram) : Decreases or increases the tilt of the sides either to the left or right.
ALIGN (trapezoidal) : Decreases or increases the bottom of the screen to be the same as the top.
ROTATE (raster rotation) : Rotates the entire display clockwise or counterclockwise.
Tools 1
MOIRÈ CANCELER: Moiré is a wavy pattern which can sometimes appear on the screen. The
pattern is repetitive and superimposed as rippled images. When running certain applications, the
wavy pattern is more evident than in others. To reduce moiré, adjust the ON/Level by using the –/+
CONTROL buttons.
BASIC CONVERGENCE: Aligns all three colors(R,G,B) to form a single color(white). The purpose of
this control is to ensure that a white line drawn on the screen is as crisp and clear as possible.
• Use the Horizontal control to adjust the alignment of the white lines in the up/down direction.
• Use the Vertical control to adjust the alignment of the white lines in the left/right direction.
