NEC MultiSync FP1350 Service Manual page 130

CONTINUE1
OK
Check the voltage at the CNPU (pin3 and pin4)on the VIDEO PWB.
Confirm that the voltage varies at each direction of the monitor and
its variable range should be between +1.5volt and +3.5volt.
OK
Check the voltage at the CNCL pin14 or TP-TMP on the VIDEO PWB.
Confirm the output voltage from approx. 100mV to 500mV
(ex:250mV at 25 )
OK
* When power switch on, Check the voltage of C4P1's both ends increase
After a few seconds, the voltage continue to increase without saturation.
(See Graph 5-8-1)
* Be sure to use voltage meter which has input impedance more than 10M
OK
CONTINUE1
NG /IC4J1,IC4L1,IC4N1 failure
/or its associated circuit failure
/IC4H1 failure
/IC4H3 failure or its associated circuit failure
NG
/LC151 (on VIDEO PWB) failure
/IC151 (on CONTROL PWB) failure
/or its associated circuit failure
7-18
CONTINUE2
NG
NG
CONTINUE2
