b-4. As following menu E appear on monitor screen, select "H. SIZE" and push "RETURN" key.
Size/Position Adjust
SIGNAL :H_MAX
1 : H. POSI
2 : V. POSI
3 : H. SIZE
4 : V. SIZE
5 : H. SIZE(MAX)
6 : END
b-5. As following menu F appear on monitor screen, push "5" key.
Then adjust data value to 255 by pushing one of "3", "6" and "9" keys.
Note: If screen is over scanned by smaller value than 255, push "RETURN" key to end
"H. SIZE" adjustment.
In this case, you must be careful not to decrease horizontal size too small at "5 : H. SIZE(MAX)"
adjustment.
Size/Position Adjust
SIGNAL :H_MAX
1 : H. POSI
2 : V. POSI
3 : H. SIZE
4 : V. SIZE
5 : H. SIZE(MAX)
6 : END
No. ?
DAC VALUE: 120
Decrease : 1(-1), 4(-5), 7(-10) Increase : 3(+1), 6(+5), 9(+10) Original : 5
END(NO WRITE) : e E
(Menu E)
Then select "5 : H. SIZE(MAX)" and decrease horizontal
size, and set up data value to 255 at "H. SIZE"
adjustment procedure.
END(WRITE) : ENTER
(Menu F)
5-32
