NEC MultiSync FP1350 Service Manual page 70

6-4. Operation
1) Programming flow chart
Read EEPROM data
6-5. Adjustment procedures
1) Start the program
a. Insert FD of software for auto ADJ I/F jig into PC.
b. Then Power on the PC, the AUTO ADJ I/F jig and Monitor.
c. As models list will appear on monitor screen, select the model number and push "RETURN" key.
d. As following message will appear on monitor screen, push "Y" or "N" key.
Size/Position Distortion Manual Adjust Program SPSC2.EXE Version 1.00
ROM READ ? (Y/N) or END (E)
Y: INITIAL DATA = READING SET
N: INITIAL DATA = PARAMETER FILE
If "Y" key is selected:
PC begins to read the data that is saved in EEPROM of the monitor, and to adjust the monitor using
the data as reference.
If "N" key is selected:
PC begins to adjust the monitor using the data saved in program disk as reference.
Note: Push "N" key, when screen size and position are not correct and data are destroyed.
Also push "N" key, if you are not sure which reference to use.
If "E" key is selected:
PC ends adjustment program.
Y
ROM READ ? (Y/N) or END
Read parameter values from disk
(1) Size / Position
(2) Distortion
(3) END
Fig 6-3 Programming flow chart of service adjustment
START
N
(Menu A)
5-29
E
END
MODEL:
FP1350-1
