ADJUSTMENT ITEMS

[A] Pre-Adjustment
1. High-Voltage Adjustment
[B] Initial Settings
1.Control Setting
[C] Main Adjustment
1. Raster Position
1-1. Horizontal Raster Position
1-2. Vertical Raster Position
2. Linearity Adjustment
2-1. Horizontal Linearity Adjustment
2-2. Vertical Linearity Adjustment
3. Horizontal / Vertical Maximum Size Adjustment
3-1. Horizontal Maximum Size Adjustment
3-2. Vertical Maximum Size Adjustment
4. Deflection Distortion Adjustment
4-1. Horizontal / Vertical Size Rough Adjustment
4-2. Picture Tilt Adjustment
4-3. Side Pincushion Balance Adjustment
4-4. Side Pincushion Adjustment
4-5. Trapezoid distortion Adjustment
4-6. Parallelogram Distortion Adjustment
4-7. Horizontal W-wave Distortion Adjustment
4-8. Vertical S-wave Distortion Adjustment
4-9. Corner Distortion Adjustment
4-10. Overall Distortion Adjustment
5. Preset Picture Size and Position Adjustment
6. Auto Adjustment (Size / Position / Distortion)
6-1. Outline explanation
6-2. Equipment for Adjustment
6-3. Connection
6-4. Operation
6-5. Adjustment procedures
7. Video Amplitude Adjustment
7-1. Settings
7-2. Video Amplitude
7-3. OSM Gain Adjustment
7-4. Cut Off Adjustment
7-5. Contrast Tracking Adjustment
7-6. Brightness Tracking Adjustment
7-7. Color Preset Adjustment
7-8. Maximum Brightness Adjustment
8. Focus Adjustment
9. Purity
10. Convergence Adjustment
11. Auto Adjustment
12. Factory settings for shipping
[D] Reference
1. Adjustment Signal
2. Adjustment Signals Timing
3. Position of Connector / Test point of Adjustment
NOTE; This MARK is important adjustment item for products safety.
(When circuit board energizing is examined.)
