2) Adjustment procedure
Adjust monitor in following steps.
a. Distortion adjustment
b. H. SIZE(MAX) adjustment
c. V. SIZE(MAX) adjustment
d. Size / Position adjustment
a. Distortion adjustment
a-1. The following menu B will appear on screen.
Size/Position Distortion Manual Adjust Program SPSC2.EXE Version 1.00
1 : Size / Position
2 : Distortion
3 : END
"1 : Size / Position"
"2 : Distortion"
"3 : END"
a-2. Select "Distortion" while menu B is displayed, and push "RETURN" key.
a-3. Input the adjustment signal that is specified as "80: TOTAL1 (1024*768(75))" on menu D.
a-4. Then, following menu will appear on monitor screen. For getting good distortion, adjust each
items on "Distortion Adjustment" with pushing "1", "4", "7", "3", "6" and "9" keys.
Note: Distortion adjustment signal may differ from another type of monitor in some cases.
In this case, use signal displayed on screen menu.
a-5. If adjustment is ended, push "RETURN" key to end the adjustment.
(Distortion data values of all preset signals are written by this operation.)
Distortion Adjust
1 : ROTATION
2 : PARALLELOGRAM
3 : TRAPEZOID
4 : PIN CUSHION
5 : PINCUSHION BALANCE
7 : V LINEAR
8 : V LINEAR BALANCE
9 : S_WAVE
10 : W_WAVE
11 : UP CORNER
12 : UP CORNER BALANCE
13 : LOW CORNER
14 : LOW CORNER BALLANCE
15 : END
No. ? _
(Menu B)
: Adjustment of size and position
: Adjustment of distortion
: Return to start menu screen
No. ? _
Note: Above menu may differ in some models.
MODEL:
FP1350-1
5-30
MODEL:
FP1350-1
(Menu C)
