NEC MultiSync FP1350 Service Manual page 119

CONTINUE
NG
Check IC7F1 input voltage
OK
Check the heater controlled voltage
NG
IC801 on the VIDEO PWB (PWB-567A) failure.
OK
Check the G1 voltage
NG
D7K1, R7K2, Q7K1, Q7K3 or Q7K2 on the VIDEO PWB (PWB-567A) failure.
OK
CRT failure.
CN-HT failure.
NG
LC901, LC903, R7F5, C764 or CN-HT failure.
OK
IC7F1 failure.
Measure the voltage at CN-HT pin 1 on the CRT PWB (PWE-567C). Normally,
the G1 voltage's high level is OV.
Measure the voltage at IC7F1 pin 5 on the CRT PWB (PWE-
567C). The voltage is approx. 8.5V.
Measure the voltage at IC7F1 pin 2 on the CRT PWB
(PWE-567C). The voltage is 0V.
7-7
