NEC MultiSync FP1350 Service Manual page 92

TIMING NAME 1 VGA350
Pixel Clock 28.322[MHz]
H.Frequency 31.469[kHz]
V.Frequency 70.086[Hz]
H.Tortal Time 900 [dots] 31.778 [us]
H.Addr Time 720 [dots] 25.778 [us]
H.Blank Time 180 [dots]
H.Front Porch 18 [dots]
H.Sync Time 108 [dots]
H.Back Porch 54 [dots]
V.Tortal Time 449 [lines] 14.268 [ms]
V.Addr Time 350 [lines] 11.122 [ms]
V.Blank Time 99 [lines] 3.146 [ms]
V.Front Porch 37 [lines] 1.176 [ms]
V.Sync Time 2 [lines] 0.064 [ms]
V.Back Porch 60 [lines] 1.907 [ms]
Scan Type Non-interlaced
H.Sync Polarity Positive
V.Sync Polarity Negative
Separate
TIMING NAME 6 MAC640*480
Pixel Clock 30.240[MHz]
H.Frequency 35.000[kHz]
V.Frequency 66.667[Hz]
H.Tortal Time 864 [dots] 28.571 [us]
H.Addr Time 640 [dots] 21.164 [us]
H.Blank Time 224 [dots]
H.Front Porch 64 [dots]
H.Sync Time 64 [dots]
H.Back Porch 96 [dots]
V.Tortal Time 525 [lines] 15.000 [ms]
V.Addr Time 480 [lines] 13.714 [ms]
V.Blank Time 45 [lines] 1.286 [ms]
V.Front Porch 3 [lines] 0.086 [ms]
V.Sync Time 3 [lines] 0.086 [ms]
V.Back Porch 39 [lines] 1.114 [ms]
Scan Type Non-interlaced
H.Sync Polarity Negative
V.Sync Polarity Negative
Composite + Sync On G
2 VGA400
28.322[MHz]
31.469[kHz]
70.087[Hz]
900 [dots] 31.777 [us]
720 [dots] 25.422 [us]
6.356 [us] 180 [dots] 6.355 [us]
0.636 [us] 18 [dots] 0.636 [us]
3.813 [us] 108 [dots] 3.813 [us]
1.907 [us] 54 [dots] 1.907 [us]
449 [lines] 14.268 [ms]
400 [lines] 12.711 [ms]
49 [lines] 1.557 [ms]
12 [lines] 0.381 [ms]
2 [lines] 0.064 [ms]
35 [lines] 1.112 [ms]
Non-interlaced
Negative
Positive
Separate
7 VESA640*350@85Hz
31.500[MHz]
37.861[kHz]
85.080[Hz]
832 [dots] 26.413 [us]
640 [dots] 20.317 [us]
7.407 [us] 192 [dots] 6.095 [us]
2.116 [us] 32 [dots] 1.016 [us]
2.116 [us] 64 [dots] 2.032 [us]
3.175 [us] 96 [dots] 3.048 [us]
445 [lines] 11.754 [ms]
350 [lines] 9.244 [ms]
95 [lines] 2.509 [ms]
32 [lines] 0.845 [ms]
3 [lines] 0.079 [ms]
60 [lines] 1.585 [ms]
Non-interlaced
Positive
Negative
Separate
3 VGA480 4 640*400@70Hz
25.175[MHz]
31.469[kHz]
59.940[Hz]
800 [dots] 31.778 [us] 800 [dots]
640 [dots] 25.422 [us] 640 [dots]
160 [dots] 6.356 [us] 160 [dots]
16 [dots] 0.636 [us] 17 [dots]
96 [dots] 3.813 [us] 64 [dots]
48 [dots] 1.907 [us] 79 [dots]
525 [lines] 16.683 [ms] 449 [lines]
480 [lines] 15.253 [ms] 400 [lines]
45 [lines] 1.430 [ms] 49 [lines]
10 [lines] 0.318 [ms] 13 [lines]
2 [lines] 0.064 [ms] 2 [lines]
33 [lines] 1.049 [ms] 34 [lines]
Non-interlaced Non-interlaced
Negative
Negative
Separate
8 VESA640*400@85Hz 9 VESA640*480@75Hz
31.500[MHz]
37.861[kHz]
85.080[Hz]
832 [dots] 26.413 [us] 840 [dots]
640 [dots] 20.317 [us] 640 [dots]
192 [dots] 6.095 [us] 200 [dots]
32 [dots] 1.016 [us] 16 [dots]
64 [dots] 2.032 [us] 64 [dots]
96 [dots] 3.048 [us] 120 [dots]
445 [lines] 11.754 [ms] 500 [lines]
400 [lines] 10.565 [ms] 480 [lines]
45 [lines] 1.189 [ms] 20 [lines]
1 [lines] 0.026 [ms] 1 [lines]
3 [lines] 0.079 [ms] 3 [lines]
41 [lines] 1.083 [ms] 16 [lines]
Non-interlaced Non-interlaced
Negative
Positive
Separate
5-51
5 800*600@60
25.175[MHz]
31.467[kHz]
70.086[Hz]
31.778 [us] 1056 [dots]
25.422 [us] 800 [dots]
6.356 [us] 256 [dots]
0.675 [us] 40 [dots]
2.542 [us] 128 [dots]
3.138 [us] 88 [dots]
14.268 [ms] 628 [lines]
12.711 [ms] 600 [lines]
1.557 [ms] 28 [lines]
0.413 [ms] 1 [lines]
0.064 [ms] 4 [lines]
1.080 [ms] 23 [lines]
Non-interlaced
Negative Positive
Negative Positive
Separate Separate
10 XGA
31.500[MHz]
37.500[kHz]
75.000[Hz]
26.667 [us] 1264 [dots]
20.317 [us] 1024 [dots]
6.349 [us] 240 [dots]
0.508 [us] 8 [dots]
2.032 [us] 176 [dots]
3.810 [us] 56 [dots]
13.333 [ms] 408 [lines]
12.800 [ms] 384 [lines]
0.533 [ms] 24 [lines]
0.027 [ms] 0 [lines]
0.080 [ms] 4 [lines]
0.427 [ms] 20 [lines]
Interlaced
Negative Positive
Negative Positive
Separate Separate
40.000[MHz]
37.879[kHz]
60.317[Hz]
26.400 [us]
20.000 [us]
6.400 [us]
1.000 [us]
3.200 [us]
2.200 [us]
16.579 [ms]
15.840 [ms]
0.739 [ms]
0.026 [ms]
0.106 [ms]
0.607 [ms]
44.900[MHz]
35.522[kHz]
87.064[Hz]
29.577 [us]
22.806 [us]
6.771 [us]
0.535 [us]
3.029 [us]
3.207 [us]
23.839 [ms]
22.715 [ms]
1.124 [ms]
0.089 [ms]
0.177 [ms]
0.858 [ms]
