- Page 1 U S E R ' S M A N U A L MultiSync FP1355...
-
Page 2: Table Of Contents
Index Warning ....................1 Contents ....................2 Quick Start ................... 3 Controls ....................5 Recommended Use ................9 Specifications ..................11 Features ....................12 Troubleshooting ................. 13 TCO’99....................14... -
Page 3: Warning
WARNING TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE FULLY INSERTED. REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. -
Page 4: Contents
Contents Your new NEC MultiSync FP1355 monitor box* should contain the following: • MultiSync FP1355 with tilt/swivel base • Power Cord • Signal Cable (D-sub to DVI-A) • USB Cable • User’s Manual • Warranty Card Signal Cable USB Cable... -
Page 5: Quick Start
15-pin mini D-SUB end of the captive signal cable to the MultiSync FP 1355 Macintosh cable adapter on the computer (Figure B.1). Tighten all screws. NOTE: To obtain the MultiSync FP1355 Macintosh cable adapter, contact NEC Australia Pty. Ltd. 4. For download information on the Windows 95/98/2000/Me INF file for ®... - Page 6 Quick Start –continued Detachable Signal Cable Macintosh Adapter (not included) 15-pin mini D-SUB Figure B.1 Power Cord Figure C.1 Power Button Figure D.1...
-
Page 7: Controls
Controls OSM (On-Screen Manager) control buttons on the front of the monitor function as follows: Main Menu Sub-Menu Exits the OSM menu. Exits to the OSM controls EXIT main menu. Moves the highlighted Moves the highlighted area CONTROL area up/down to select up/down to select one of the one of the controls. -
Page 8: Geometry Controls
Kelvin. If a setting is adjusted, the name of the setting will change from Kelvin to Custom. Red, Green, Blue: NEC’s AccuColor Control System decreases or increases the monitor’s red, green or blue color guns depending upon which is selected. The change in color will appear on screen and the direction (decrease or increase) will be shown by the bars. - Page 9 While in the sub-menus (Top Left, Top Right, Bottom Left or Bottom Right), use the –/+ control buttons to fine tune the GlobalSync corrections. Note: NEC recommends that you perform GlobalSync correction while running a typical application such as a spreadsheet or text document.
- Page 10 Controls –continued Information Display Mode: Indicates the current mode and frequency setting of the monitor. Monitor Info: Indicates the model and serial numbers of your monitor. Refresh Notifier: A message will advise you if the refresh rate of the signal being applied to the monitor by the computer is too low.
-
Page 11: Recommended Use
FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING THE MULTISYNC FP1355 COLOR MONITOR: • DO NOT OPEN THE MONITOR. There are no user serviceable par5ts inside and opening or removing covers may expose you to dangerous shock hazards or other risks. - Page 12 Recommended Use –continued CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE FOLLOWING WHEN YOU POSITION THE MONITOR: • Adjust the monitor height so that the top of the screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen.
-
Page 13: Specifications
1024 x 768 @ 50 to 144 Hz 1280 x 1024 @ 50 to 110 Hz 1600 x 1200 @ 50 to 95 Hz ...... NEC-Mitsubishi Electronics Display cites 1800 x 1350 @ 50 to 85 Hz recommended resolution a 85 Hz for 1800 x 1440 @ 50 to 80 Hz optimal display performance. -
Page 14: Features
Features Flat Aperture Grille CRT: Delivers an unparalleled viewing experience with a virtually flat image, eliminating distortion and reducing glare so that what you see on-screen is what you get on your printed output. The striped phosphor alignment of the CRT delivers superior vertical definition with improved brightness for more uniform image contrast. -
Page 15: Troubleshooting
Troubleshooting No picture • Display card should be completely seated in its slot. • Power Button and computer power switch should be in the ON position. • Signal cable should be completely connected to display card/computer. • Check connector for bent or pushed-in pins. Image is scrolling or unstable •... -
Page 16: Tco'99
TCO’99 Congratulations! You have just purchased a TCO’99 approved and labeled product! Your choice has provided you with a product devel- oped for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products. - Page 17 TCO’99 –continued accumulative* processes. Flame retardants have been found in human blood and researchers fear that disturbances in foetus development may occur. TCO’99 demand requires that plastic components weighing more than 25 grams must not contain flame retardants with organically bound chlorine and bromine. Flame retardants are allowed in the printed circuit boards since no substitutes are available.
-
Page 18: Declaration Of The Manufacturer
Declaration of the Manufacturer We hereby certifiy that the color monitor MultiSync FP1355 (NSZ2102STTUW) is in compliance with Council Directive 73/23/EEC: – EN 60950 Council Directive 89/336/EEC: — EN 55022 — EN 61000-3-2 — EN 61000-3-3 — EN 55024 and marked with... - Page 19 Notes...
-
Page 20: Declaration Of Conformity
Since implementation by customers of each product may vary, the suitability of specific product configurations and applications must be determined by the customer and is not warranted by NEC-Mitsubishi Electric Visual Systems Corporation. To allow for design and specification improvements, the information in this document is subject to change at any time without notice.
