Quality of Service (QoS): Managing Bandwidth More Effectively
Using QoS Types To Configure QoS for Outbound Traffic
N o t e
N o t e
Assigning a DSCP Policy Based on the Source-Port
This option assigns a previously configured DSCP policy (codepoint and
802.1p priority) to outbound IP packets (received from the specified source-
ports). That is, the switch:
Selects an incoming IP packet on the basis of its source-port on the switch.
Overwrites the packet's DSCP with the DSCP configured in the switch for
Assigns the 802.1p priority configured in the switch for the new DSCP.
(Refer to "Differentiated Services Codepoint (DSCP) Mapping" on page
Forwards the packet through the appropriate outbound port queue.
"Mixing" ToS DSCP policies and 802.1p priorities is not recommended. Refer
to the Note on page 6-10.
For more on DSCP, refer to "Terminology" on page 6-6.
Steps for Creating a Policy Based on Source-Port Types.
You can select one DSCP per source-port. Also, configuring a new DSCP for
a source-port automatically overwrites (replaces) any previous DSCP or
802.1p priority configuration for that port.)
Identify the source-port type to which you want to assign a DSCP policy.
Determine the DSCP policy for packets having the selected source-port:
Determine the DSCP you want to assign to the selected packets. (This
codepoint will be used to overwrite the DSCP carried in packets
received through the source-port from upstream devices.)
b. Determine the 802.1p priority you want to assign to the DSCP.
Configure the DSCP policy by using qos dscp-map to configure the priority
for each codepoint. (For details, refer to the example later in this section
and to "Differentiated Services Codepoint (DSCP) Mapping" on page
