Product Overview

MTX100A MPEG Recorder & Player Service Manual
The MTX100A MPEG Recorder & Player records and plays MPEG-2 transport
streams that are compliant with ATSC, DVB, and ARIB standards.
The MTX100A provides the following features:
H Data rate: 200 Mbps maximum (RAM mode); 256 Kbps minimum
H Hierarchy display of the stored or captured transport stream
H 188, 204, 208 bytes packet size, S-TMCC, M-TMCC, non transport stream,
and partial transport stream output formats
H Real-time updating of transport stream parameters; continuity_counter,
PCR/PTS/DTS, TOT/TDT/STT, NPT, and Reed Solomon (ISDB-T transport
stream only)
H Continuous recording of captured streams
H PCR jitter insertion
H Triggered stream capture
H Full remote control using Ethernet interface
H Scheduler application for automated stream playout and record (Option SC
only)
H Optional ASI, universal parallel/serial, IEEE1394/ASI, and SMPTE310M/
ASI/SPI interfaces available
The MTX100A includes the ReMux application software that provides the
capability to create a transport stream of super frame structure defined in the
ISDB-S systems from an MPEG2 transport stream.
