Reinstalling The Mtx100A Application; Restoring The Ieee1394B Port Speed Setting - Tektronix MTX100A Service Manual

Using the Recovery Discs

Reinstalling the MTX100A Application

Installing the Parallel
Driver (Option SC Only)

Restoring the IEEE1394b Port Speed Setting

4-48
Perform the following procedure to reinstall the MTX100A application software:
1. Insert the MTX100A & RTX100A Application Software Recovery Disc
into the DVD drive.
2. Double- -click the E: drive icon (substitute your DVD drive letter if it is
different than E).
3. Double- -click the Application_Software folder.
4. Double-click the setup.exe icon. This installs the MTX100A application
software.
Perform the following procedure to reinstall the parallel driver:
1. Double-click the Driver folder in the MTX100A & RTX100A Application
Software Recovery Disc.
2. Double-click the SSD5411-32bit.exe icon.
3. Click Next in the resulting window. The License Agreement window
appears.
4. Select I accept the terms in the license agreement, and then click Next.
The Destination Folder window appears.
5. Click Next. The Setup Type window appears.
6. Select Complete and click Next. The Ready to Install Program window
appears.
7. Click Install to proceed with installation.
8. When the InstallShield Wizard Completed window appears, click Finish
to complete the installation.
The IEEE1394 port speed of the MTX100A is set to S400/S800 at the factory.
However, when you reinstall the Windows XP operating system, this setting
returns to the default value (S400). After you reinstall the operating system,
perform the following procedure to restore the IEEE1394b port speed setting:
1. Select Start > Run to open the Run dialog box.
2. Enter regedit in the Run dialog box, and then click OK. This opens Registry
Editor window.
MTX100A MPEG Recorder & Player Service Manual
