A170 SMPTE310M/ASI/SPI Interface Module (Option 07)

A12
Main Board
J110

Figure 6-6: A170 SMPTE310M/ASI/SPI Interface module connections

6-10
Figure 6-6 shows the A170 SMPTE310M/ASI/SPI Interface module and how it
interconnects with the A20 PCI Backplane board and the A12 Main board.
A170
174-B924-00
J900
J310
A20
PCI Backplane Board
SMPTE310M/AS/SPII Interface module
J500
J600
J400 SPI Input
Card Edge
J120
MTX100A MPEG Recorder & Player Service Manual
SMPTE310M/
ASI Input
SMPTE310M/
ASI Output
