Troubleshooting
(E)
No
Is the Record Source
Select Record > Source> SPI.
menu set to SPI?
Yes
Can a stream data
No
be acquired from the
SPI In/Out connector?
Yes
Replace the A12 Main board.
Done.
Figure 4-22: Troubleshooting procedure (7)
Front
J220
J170
Figure 4-23: A20 PCI Backplane board view- back side
4-44
MTX100A MPEG Recorder & Player Service Manual
