Step  Connecting Telemetry Cameras

Simple Dome Connection

Pin connections for RS485 connection to a dome on serial port 3/4 are:
If the dome is being connected using an ��S485 connection, the dome address should be set to
match the camera input number on the D�-IP Server i.e. if the dome is connected to video input
3, the camera address should be '03'.
Dennard 00 & 00 Domes
A Dennard 2040/2060 Dome can be connected via either co-axial telemetry or RS485 twisted
pair.
If using co-a�ial telemetry the address switches should be set as:
DM Oracle Domes
A DM Oracle dome can be connected via either co-axial telemetry or RS485 twisted pair. Oracle
Domes are configured using the specific pages available in the Configuration menu, refer to
'Oracle Dome Configuration' for more information.
The DM Oracle Dome has three address switches, refer to the Oracle Dome documentation for
more information on hardware confguration.
1
Dome Cable D�-IP Server Serial Connector
��ellow 1 TX+
Green 9 TX-
�lue switch - F ��ellow switch - D
UTC
Red - 1
�lue - N���
��ellow - N���
Serial
Red - 2
�lue - Camera Number
��ellow - Camera Number
