Page 1 DV-IP Server Installation and Operation Guide...
Page 2: Table Of Contents
Appendix C ....................132 Appendix D ....................133 Whilst every attempt is made to ensure these manuals are accurate and current, Dedicated Micros reserve the right to alter or modify the specification of the machine described herein without prejudice. Dedicated Micros ©2008...
Page 3: Introduction
Available with 8, 12 or 16 camera inputs, all offering telemetry control, the DV-IP Server has built in Alarm functionality and onboard Activity detection software. The IP Camera support function allows digital video streams from IP addresses to be viewed and recorded.
Page 4: Features
Features The DV-IP Server from Dedicated Micros is equipped with an array of valuable features designed to enhance the operator experience. •� 8, 12 or 16 camera input options 8, 12 or 16 camera input options •� Up to 100pps recording at QCIF to 4CIF resolution •�...
Page 5: Design Of The Manual
�ith no need for a telemetry keyboard, users are able to use Pan & Tilt control of a Dedicated Micros Oracle Dome simply by clicking an area of the monitor. The camera will instantly respond, positioning the selected area in the middle of the screen, ideal for tracking movement through a scene.
Page 6: Important Safeguards
This reminder is provided to call the CCT� system installer’s attention to �rt. 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. Dedicated Micros ©2008...
Page 7 CE Mark If this product is marked with the CE symbol it indicates compliance with all applicable directives. Directive 89�336�EEC. � ‘Declaration of Conformity’ is held at Dedicated Micros �td., 1200 Daresbury Park, Daresbury, Cheshire, ��4 4HS, U�. Laser The unit supports an integrated CD�D�D writer, the following are additional warnings associated with installing and operating the CD�D�D writer, please pay particular attention to this information.
Page 8: Installing The Unit
D�-IP Server �uickstart guide If any of these items are missing, please contact Dedicated Micros Technical Support team. Note: Before installing the DV-IP Server DVR, carefully read all Safety Instructions and the following information on where the unit should be located.
Page 9: Electrical Connections
PC with CD ��OM drive and connection to the same network as the D�-IP Server unit �Recommended� Quick Overview of DV-IP Server Record Settings DV-IP Server units provide out of the box: High performance recording on �� cameras with minimal configuration. Consistent recording duration and smooth motion video per camera regardless of the number of cameras.
Page 10: Front Panel Connections
HDD (Hard Disk Drive) - This will ��ash when images are being stored to the hard disk Network - The Network �ED will be green to indicate a connection Rear Panel connections 16 Input model 12 Input model 8 Input model ��E��P�NE�D�GSE��E��.EPS Dedicated Micros ©2008...
Page 11: Alarms And Relays
2� US�2.0 connectors Infra-Red Input connector for IR Remote Control Extender ��J45 Ethernet network connector, 10�100 Mb�s Ethernet Network ��D ��J12 connector for use with Dedicated Micros telemetry keyboards (��C1, ��C2) ��J12 e�pansion port for future use S�T� 2� E-Sata ports available for storage e�pansion Power PO�E��...
Page 12: Installing The Dv-Ip Server
This procedure shows the sixteen camera input version. Step 1 Connecting Video The DV-IP Server supports up to 8, 12 or 16 connected Video Inputs �dependant on model� via the 75Ω �NC connectors. Connect cameras to the video inputs, starting from input 1.
Page 13 • ��eplay - all audio through a local �udio output (not supported when �udio out is used as a challenge�P� source) Note: The Audio output can be configured as a challenge output or as a replay output. Dedicated Micros ©2008...
Page 14 �hen the unit is powered up, the network address can be found by viewing on a local monitor and navigating to Configuration Menu pages:System Settings->System->IP �ddress. Refer to ‘Configuring The Unit’ for further guidance on locating the unit’s IP address and for details of the default DNS (Domain Name Server) address. Dedicated Micros ©2008...
Page 15: Relay Connector
This functionality is part of the advanced alarms supported on Net�u Connected products and includes features required for Central Monitoring. It is compatible with the �ritish Standard �S8418. Relay Connector Alarm Input Connection 1 - 20 1-20 21-25 Earth Common Dedicated Micros ©2008...
Page 16 Closed, the resistive value is 1� ohms, as the circuit does not see the 5.6� ohm resistor. Open Circuit Tamper, the resistive value is infinity as the circuit has been cut and therefore is ‘open’. Short Circuit Tamper, the resistive value is 0 ohms. Dedicated Micros ©2008...
Page 17 The D�-IP Server supports Dedicated Micro keyboards DM��C1 and DM��C2. Connect either of these keyboards via the ��D connector situated on the rear of the unit. Note: Refer to ‘Unit Operation’ for further guidance regarding supported keyboards. Dedicated Micros ©2008...
Page 18: Simple Dome Connection
The DM Oracle Dome has three address switches, refer to the Oracle Dome documentation for more information on hardware confguration. Red - �lue - N�� ellow - N�� Serial Red - �lue - Camera Number ��ellow - Camera Number Dedicated Micros ©2008...
Page 19 The D�-IP Server has an internal power supply unit. Connect the mains lead to the unit and then to the wall socket, or to a fused spur connection. Check local regulations before installation. Some countries require an �larm�Security device be connected to a fused spur and not a wall outlet socket. Dedicated Micros ©2008...
Page 20: Advanced Installation
The unit’s operating system will continue to utilise the internal hard disks if the e�ternal hard drive encounters a problem. Dedicated Micros Managed Storage Expansion units � DM Managed Storage E�pansion unit is connected via the S�T� port. � Managed Storage unit provides high capacity, environmentally managed storage in a single bo�.
Page 21: Configuring The Unit
• ’ ’ yourname‘ is the name assigned via the Network menu. Note: To activate an assigned DNS address, it will be necessary to reboot the unit. The DV-IP Server can be rebooted via System Settings:Maintain:- Reset. 6.11 IMPORTANT: To set the time and date on the unit, navigate to System Settings:-Time and Date.
Page 22 Accessing the Configuration Webpages The unit can be configured using the webpages. To access these: �aunch Internet E�plorer (or similar web browser package). Type the U�� for the unit (IP or DNS address). The Opening menu page will be displayed. Dedicated Micros ©2008...
Page 23: Remote Control
Note: To use the IR Remote Control, the Remote IR Extender must be connected to the IR socket on the unit. Not all buttons on the IR Remote Control are relevant for the DV-IP Server. Button Switches the ��emote Control to ‘T�’...
Page 24 The Number pad should be used to select specific cameras and preset positions when available. Use the Playback buttons to interrogate recorded images. Use the �I�E button to switch from Playback or menus to a �I�E display. Dedicated Micros ©2008...
Page 25: Main Menu
Viewer features. Select the Download menu tab to access the various Download sub-options. Select from: •� Product Manual Select to open an electronic version of the DV-IP Server Installation & Operation Guide. • Obser�er Manual Select to open an electronic version of the Net�u Obser�er User Guide.
Page 26: Navigating The Configuration Menus
When accessing the configuration menus, the menu tree will be displayed. The configuration pages are navigated using the menu tree (displayed on the left of each page). Selecting one of the menu options will display the relevant page. �ssociated sub-menus will then be available. Dedicated Micros ©2008...
Page 27: Entering Alpha-Numeric Data Via A Local Monitor
The cursor will then progress, ready for the ne�t character entry. Note: A USB Keyboard (not supplied) can be connected via one of the USB ports on the unit. The USB Keyboard can then be used to enter alpha-numeric data via the local menus. Dedicated Micros ©2008...
Page 28 Navigating away from a page (clicking on a different option on the menu tree) will automatically save any changed settings. To undo changes made to any menu, select the ��efresh (Purple) option. To undo changes made to any menu, select the ��efresh (Purple) option. Dedicated Micros ©2008...
Page 29: System Settings
Email reporting, webcam support and control of the display resolution. The Maintain page allows the current configuration to be saved, and for previously saved settings to be loaded. It also enables easy upgrade of the system software. Dedicated Micros ©2008...
Page 30 DHCP server. Software ��evision This identifies the version of software the unit is running. Codec ��evision This identifies the codec version the unit is running. �ebpage ��evision This identifies the webpage version the unit is running. Dedicated Micros ©2008...
Page 31: Unit Status
‘Off’ signifies that it is active as a codec. Note: The ‘On’/‘Off’ text will only be displayed if viewing the Unit Status menu remotely over an IP connection. Note: Any codec can be set to operate as a framestore. Dedicated Micros ©2008...
Page 32 Those camera channels with cameras connected will be highlighted light green. Those not in use will appear dark green. Failed Cameras Those camera channels where the connection is deemed to have failed will be highlighted light green. Those working correctly will appear dark green. Dedicated Micros ©2008...
Page 33: Alarm Status
This menu details information regarding the status of the unit’s alarm contacts, alarm zones and relay outputs. �larm Contacts�Zones��elay Outputs �larm Contacts, �larm Zones and ��elay Outputs that are in an ‘active’ state are shown light green. ‘In-active’ ones appear dark green (not illuminated). Dedicated Micros ©2008...
Page 34 If required, the language can also be changed for the current session only. System �anguage Select to change the system language setting. Note: A server reboot will be required to implement system language changes. The DV-IP Server The DV-IP Server can be rebooted via System Settings:Maintain:- Reset.
Page 35: Time And Date
Use this button to synchronise the time of the unit to that of the PC being used to view the webpages. Note: The PC Time and Sync Time options will only be available if viewing the menu via the webpages. Dedicated Micros ©2008...
Page 36: Serial Ports
Serial Ports This menu allows configuration of the unit’s Serial ports. Refer to ‘Installing the DV-IP Server’ for Refer to ‘Installing the DV-IP Server’ for installation information. Serial Port These are the four serial ports available. Port Config The serial ports can be configured to specific uses.
Page 37 Remote Video Receiving Centre (RVRC) can be recorded via input 2. This combined audio is then RVRC) can be recorded via input 2. This combined audio is then available on Audio Output 1. Refer to ‘Installing the DV-IP Server’ for audio hardware installation efer to ‘Installing the DV-IP Server’ for audio hardware installation information.
Page 38 Select this option to enable automatic FTP downloads to upgrade the unit and�or the webpages, refer to ‘Network Settings-FTP Download’ for more information. Note: When de-selected here, the ‘Automatic FTP Download’ menu will no longer be displayed in the menu tree. Dedicated Micros ©2008...
Page 39 User Logging function. Comb Filter Enable this option to activate the Comb Filter function. Comb Filter can help improve the fine details of a video signal image by filtering the luminance and chrominance separation process. Dedicated Micros ©2008...
Page 40 Select to cycle the power to the unit. Software Software Upgrade (��ellow) Select to perform a software upgrade. The unit will search any connected media device for relevant data. Note: For the latest software upgrades, please refer to the Dedicated Micros website: www.dedicatedmicros.com Dedicated Micros ©2008...
Page 41: Console Settings
Selected camera feeds can be viewed and controlled via the Viewer menus. Refer to the individual menus for more information. The System Config page dictates which cameras and systems the DV-IP Server will connect to, and controls how the video feeds will be displayed.
Page 42: System Config
Select the cameras to be accessed. To select individual cameras, use the format 1,3,5 or 1:3:5 etc. To select a range of cameras, use the format 1-3 or 1_3 etc. �ll connected, non-covert cameras within the range will be added in numerical connection order. Dedicated Micros ©2008...
Page 43: Systems Overview
Identifies the name assigned to the server the camera is located on. Configure Server Select the Config Pages option to access the configuration pages for the selected Server. Note: Passwords maybe required to successfully access server configuration pages. Dedicated Micros ©2008...
Page 44 Viewer Defaults The DV-IP Server’s Viewer function allows remote users to simulate local operation over a network. This menu allows configuration of settings for the Viewer function. Refer to ‘Operating The Viewer’ for more information regarding the Viewer. Default Image Format Images requested from the connected D��s and�or Net�u...
Page 45 If accessing multiple units via a remote connection, all can be assigned the same �iewer applet. This will lessen the load time required when accessing different D��s�Servers via the �iewer. Dedicated Micros ©2008...
Page 46 Spot Sequence Setup �ll of the unit’s camera input channels are shown. To include any of these camera channels in the spot monitor sequence, selected the accompanying tickbo�. Dedicated Micros ©2008...
Page 47: Map Config
Select to increase size of hotspot. Hotspot X coord Use to position the centre of the hotspot along the X a�is e.g. entering 20 would place the hotspot centre 20 pi�els from the left edge of the map. Dedicated Micros ©2008...
Page 48 20 degrees to the right of its ‘origin’ position, 180 would send it to face the opposite direction of its origin position Refer to the ‘Viewer Menus-PTZ Profile menu‘ for information on establishing an Origin position for a PTZ camera. Dedicated Micros ©2008...
Page 49: Map Data
The Map Data menu allows Map Config data to be Imported/Exported. This enables map data to be saved and stored for future use, or used between multiple DV-IP Servers. Note: The Map Data menu will only be available when viewing the menu pages remotely i.e. via the webpages.
Page 50: User Accounts
Assigning Local Users access privileges will limit access to the �iewer pages for local users. �hen implemented, the local user will be prompted for a username and password before access to the �iewer pages (via the main menu) will be granted. Dedicated Micros ©2008...
Page 51 Modify or Delete. Note: If viewing the User Accounts page via a local monitor and navigating with the I.R Remote Control. Press the right directional button from the menu tree to access the Account List. Dedicated Micros ©2008...
Page 52: Camera Settings
The I.P Camera page allows configuration of incoming digital video streams originating from an IP address. The Camera Setup page allows the colour and contrast settings for each individual camera to be adjusted (with a dynamic preview available). The Camera Telemetry page enables telemetry capable cameras to be configured. Dedicated Micros ©2008...
Page 53 Note: The arrow button displayed next to each textbox allows settings to be replicated for those cameras listed below. This will only affect the adjacent option i.e. Mode arrow will replicate the Mode setting to cameras below the clicked arrow. Dedicated Micros ©2008...
Page 54: Ip Camera
Select the type of IP camera i.e. if the stream is originating from Select the type of IP camera i.e. if the stream is originating from a Net�u Connected server select ‘Net�u Server’. If from a Net�u camera such as a Dedicated Micros CamVu 2000, select ‘Net�u Camera’. U��...
Page 55: Camera Setup
Select a colour value from -8 to +8 via the slidebar or enter a number directly into the accompanying te�tbo�. Camera Contrast Select a contrast value from -8 to +8 via the slidebar or enter a number directly into the accompanying te�tbo�. Dedicated Micros ©2008...
Page 56: Camera Telemetry
Note: The arrow button displayed next to each textbox allows settings to be replicated for those cameras listed below. This will only affect the adjacent option i.e. Telemetry arrow will replicate the Telemetry setting for cameras below the clicked arrow. Dedicated Micros ©2008...
Page 57: Record Settings
The Holiday and Weekend page enables Set mode to be activated for individual dates i.e. public holidays or weekends. The Protect Video page allows previously recorded data to be protected and retained. If needed, all recording can be halted and saved video deleted. Dedicated Micros ©2008...
Page 58 Select from Normal ��ate MPEG4 5pps, Normal ��ate JPEG 1pps or MultiMode recording. ��ecord Duration�Enhance �uality The recording duration can be limited to a set number of days; allowing the recording quality to be enhanced for a shorter storage period. Dedicated Micros ©2008...
Page 59: Simple Record
Note: It is recommended that the Pre-Alarm option in the ‘Alarm Settings-Zone Input’ menu be set to the same value as the Pre-Trigger setting. This will ensure successful playback of high quality Pre-Trigger images. High quality pre-trigger images will only playback properly if review (playback) starts prior to the pre-trigger initiation. Dedicated Micros ©2008...
Page 60 Select from Ma�imum, �ery High, High, Medium, or �ow. Select User Defined to use settings established in the �dvance Profile ��ecord menu. Note: The higher the Quality setting, the greater the storage space used. Dedicated Micros ©2008...
Page 61: Advanced Record
�larm or Event. Note that Set and Override schedules will be used only when Timed Schedules are applied. Refer to ‘Schedule’ for further information. Comp Select image compression format (MPEG or JPEG). ��es Select image resolution format (�CIF, CIF, 2CIF or 4CIF). Dedicated Micros ©2008...
Page 62 If JPEG is selected, the figure entered here will be the size of the JPEG transmitted (in �bytes). JPEG file sizes can be configured within the range of 5-45�bytes. This shows the number of pictures recorded per second. Dedicated Micros ©2008...
Page 63: Ip Record
Select image compression format (MPEG or JPEG). ��es For both MPEG and JPEG recording, select either High, Medium or �ow quality resolution settings. Note: To view a local IP camera ‘live’, IP recording should be set to MPEG. Dedicated Micros ©2008...
Page 64 (EO�) option enables the �eyswitch to detect any changes in the electronic input resistance. � change outside the e�pected values will result in a Tamper �larm (short circuit or open circuit) being detected and the system switching to alarm mode. Dedicated Micros ©2008...
Page 65 Start Select a Start day and time for �eekend mode. Select an End day and time for �eekend mode. Note: Weekend mode will remain activate each week until deselected. Dedicated Micros ©2008...
Page 66: Protect Video
This dialog bo� allows a search to be made within the protected video list starting from a specific Time and Date. �ist To Date�Time This dialog bo� allows a search within the protected video list to conclude at a specific Time and Date. Dedicated Micros ©2008...
Page 67: Alarm Settings
The Global Relays page allows the four onboard relay connections and global relay settings to be configured. The VMD Configuration page enables the unit’s VMD �Video Motion Detection�� to be set-up. VMD allows a camera to automatically detect if there is any movement/changes within specfic areas of the video scene. Dedicated Micros ©2008...
Page 68: Alarm Input
Alarm Input This menu allows configuration of the alarm settings, refer to ‘Installing the DV-IP Server Unit’ for hardware installation guidance. Number This identifies which input is being configured. The unit supports This identifies which input is being configured. The unit supports 20 on-board alarms.
Page 69 Note: The arrow button displayed next to each textbox allows settings to be replicated for those cameras listed below. This will only affect the adjacent option i.e. Enabled arrow will replicate the Enabled setting to cameras below the clicked arrow. Dedicated Micros ©2008...
Page 70: Zone Input
This is the minimum time period in seconds �from the start of the alarm) that is protected from being overwritten. This time will include the alarm trigger, the pulse extension and any post alarm recording. It will not include pre-alarm images. Dedicated Micros ©2008...
Page 71 Set operation mode. Enable in Override Each alarm can be configured to be active when the unit is in a specific operation mode. Enable this for the zone alarm to be active in Override operation mode. Dedicated Micros ©2008...
Page 72: Zone Actions
Select to ensure the unit automatically downloads alarm images via an FTP connection to an FTP server. �dd Still Image This will record a still image of the trigger along with the standard recording. This can then be sent on to an e�ternal destination. Dedicated Micros ©2008...
Page 73 �larm Image Snapshot Delay This figure allows a delay to be introduced before an alarm snapshot is taken. This is used when the alarm relates to a PTZ camera which has to travel to a preset position. Dedicated Micros ©2008...
Page 74: Activity Setup
This option will insert a default square of 16 � 16 cells across the This option will insert a default square of 16 � 16 cells across the displayed video image. Clear �ll (��ellow) This option will clear all entered cells. This option will clear all entered cells. Dedicated Micros ©2008...
Page 75 Following �ctivity activation, select ‘Simple ��esponse’ to trigger specific chosen responses. Refer to ‘Activity Response Setup’ for more information. Select ‘Zone’ to apply the Zone Input rules as configured in the Zone Input menu. Refer to ‘Zone Input’ for more information. Dedicated Micros ©2008...
Page 76 This will enable �ctivity Detection when the unit is in Day (Unset) operation mode. Enable in Night This will enable �ctivity Detection when the unit is in Night (Set) operation mode. Enable in �eekend This will enable �ctivity Detection when the unit is in �eekend (Override) operation mode. Dedicated Micros ©2008...
Page 77 Select this option to establish any �ctivity Detection trigger as Select this option to establish any �ctivity Detection trigger as a Global ��elay. Therefore the relay will close when �ctivity is identified on any of the camera inputs. Dedicated Micros ©2008...
Page 78 ��elay. Therefore the relay will close when there is notification on the system that any of the enabled video inputs has camera failure (no 1� pk-to-pk signal). System Set (��elay 4) �hen selected, the unit will automatically switch to Set mode following relay activation. Dedicated Micros ©2008...
Page 79 The zone mode identifies when the reference image is taken for triggering �MD. The options are: Normal - The reference image is updated approx every second. This will only allow small changes in the scene without triggering Dedicated Micros ©2008...
Page 80 High�Medium��ow This is the resolution of the reference �MD image being displayed. ��efresh This will update the reference image to the latest view during set Dedicated Micros ©2008...
Page 81: Network Settings
Webserver. The images can then be incorporated into a web page and accessed via a standard web browser. The FTP Download page allows data to be archived to a central FTP server. This could be on receipt of an alarm, Activity activation or at a scheduled time to back-up recorded video. Dedicated Micros ©2008...
Page 82 MTU is the largest physical packet size measured in bytes that the network can transmit. �y default this figure is set to 1500bytes. M� Transmission Timeout ms This is the time (in milliseconds) the unit will wait to re-send a packet if an acknowledgement is not received. Dedicated Micros ©2008...
Page 83 PPP (Point to Point Protocol) link if data has not been transmitted or received. PPP �ink Down Timer mins If for any reason the PPP connection is lost, this is the time (in minutes) before the unit will be forced to drop the PPP connection. Dedicated Micros ©2008...
Page 84: Live Transmissions
The NetVu Connected remote viewing software will use the settings configured on this page as the defaults for JPEG & MPEG; High, Medium and Low settings. The DV-IP Server transmits live images using JPEG or MPEG image formats utilising soft codec architecture (VISP). The DV-IP...
Page 85: E Mail
If the fields are left blank the unit will use the system name to create a sender name. Display Name (Sender) This is the sender name that will be shown in the email name field. Send on Startup Select to send email notification on startup. Dedicated Micros ©2008...
Page 86 �og Email Select to log every e-mail transaction that the unit issues. Email Image ��es Select resolution settings for images sent as ‘thumbnail’ attachments. Choose from: Thumbnail, �O (low res), MED (medium res) and HI (high res). Dedicated Micros ©2008...
Page 87: Remote Reporting
This is the reference name�ID that will be presented to the ��C viewing application. It should therefore have some significance to the Operator. ��eport Startup This will send an alarm report when the unit starts up. �ny system resets will be identified. Dedicated Micros ©2008...
Page 88 � setting of ‘0’ means no limit and the unit will continue to try and connect until successful. �larm ��esponder Port This specifies the network port number used for reporting to the alarm server. In normal circumstances this should be left at the default value (23). Dedicated Micros ©2008...
Page 89 Update Interval This is the minimum update interval between each image transmitted from the unit. Select Camera Input This allows individual video inputs to be enabled for uploading to the webcam server. Dedicated Micros ©2008...
Page 90 The �eb Cam function can be: ‘�lways Enabled’, ‘Enabled when system SET’, ‘Enabled when system UNSET’ or ‘Disabled’. �ebcam ��esolution Select a High, Medium or �ow webcam resolution settings to best match the monitor settings of the operator receiving the images. Dedicated Micros ©2008...
Page 91: Ftp Download
If it is necessary to use an authentication process to access the FTP server, enter the relevant username here. Password If it is necessary to use an authentication process to access the FTP server, enter the relevant password here. Dedicated Micros ©2008...
Page 92 FTP download overrides Powermanager When selected, if the unit is in the process of an FTP download and the unit is sent into reset, the reset will not begin under the FTP process has completed. Dedicated Micros ©2008...
Page 93: Analytics & Text
The Analytics and Text menus allow configuration of the unit’s text in image and keywords functionality. Refer to the individual menus for further details. The DVIP Server is AnalyticsCapable. Please call Dedicated Micros on + 44 (0) 845 600 9500 for further information on our range of Analytics based solutions.
Page 94 Analytics Dedicated Micros has created a range of analytics components and solutions designed to work with the AnalyticsCapable DV-IP Server. The range of applications include: Automatic Number Plate Recognisition (ANPR), Object Left and Removed, Access Control, People Counting and Perimeter Protection.
Page 95: Text In Image
Select the input source for Te�t in Image data. Select ‘Off’ to switch the function off, select ‘Network to use the unit’s Network port or ‘Serial’ to use one of the unit’s serial ports (see ‘Port’ below). Dedicated Micros ©2008...
Page 96 (i.e. if a configured �eyword is detected again within the first �eyword’s pulse e�tension period, the second (and following) occurrences of the word will be ignored). Dedicated Micros ©2008...
Page 97 Zone keyword channel, refer to “Zone Input - Input”. Note: Increasing the number of keywords can significantly increase the number of stored events. Note: Refer to ‘Text In Image’ and ‘Serial Ports’ for further guidance on integrating text data. Dedicated Micros ©2008...
Page 98: Archive
Space required for archive download. �rchive Space �vailable Space currently available on CD�D�D or US� device. �rchive button Select this button to begin the �rchive process. Status During �rchiving, status messages will be displayed detailing the archive process. Dedicated Micros ©2008...
Page 99: Oracle Dome Configuration
Oracle Dome Configuration If a camera channel has a Dedicated Micros Oracle dome camera connected, the Oracle Configuration menus can be used to view settings and establish Presets, Patrols and Privacy Masks. Refer to individual menus for further details. The Status page details fundamental information regarding the status of the Oracle Dome i.e. the model type and the version of software/firmware installed.
Page 100 This identifies the version of software the camera unit is running. Firmware �ersion This identifies the version of firmware the camera unit is running. �ootloader �ersion This identifies the bootloader version of the camera unit is running. Dedicated Micros ©2008...
Page 101 Select this button to store the current preset position to the Oracle Dome camera’s memory. Goto Preset (Green) Select this button to immediately send the camera to the currently stored preset position. Delete Preset (��ellow) Select this button to delete the currently displayed preset configuration. Dedicated Micros ©2008...
Page 102 25 characters). + (��ed) Use the + button to zoom the camera view IN. - (�lue) Use the - button to zoom the camera view OUT. Navigation �uttons Use the four navigation buttons to position the camera view. Dedicated Micros ©2008...
Page 103 Select the Dwell time (in seconds) the Patrol will remain at this Preset position. Save �Grey� Select to store the preset sequence to the unit and the �racle Dome camera memory. Play (��ed) Select to activate (play) the current patrol sequence. Dedicated Micros ©2008...
Page 104: Privacy Masks
Finish New (Green) Select this option to finish creation of privacy mask. Show (��ellow) Select this option to show camera view with e�isting privacy mask displayed. Delete (�lue) Select this option to delete the currently displayed privacy mask. Dedicated Micros ©2008...
Page 105 ‘stacked’ in one segment of the screen. Engineer Display Toggle to switch the Engineer Display te�t On�Off. This function is intended for future development. Save �Grey� Select to store �SD Settings to the unit and the �racle Dome camera memory. Dedicated Micros ©2008...
Page 106 If the connected �racle Dome camera is part of the HyperD non-wide dynamic range, select to activate the unique wide dynamic function. Digital Zoom Select to activate the Digital Zoom function e.g. the camera will zoom within the actual image. Dedicated Micros ©2008...
Page 107 1 and 100 until the optimum image quality is reached. UTP �oost If the Oracle Dome camera is connected to the unit via twisted pair cabling. The UTP �oost function can be activated to improve signal strength. Dedicated Micros ©2008...
Page 108: Event Settings
Select the time ( in seconds) for which the camera is inactive i.e. no operator input, before returning to its home position. Save �Grey� Select to store Event Settings to the unit and the �racle Dome camera memory. Dedicated Micros ©2008...
Page 109 Unit Operation The DV-IP Server unit can be operated via the Viewer menus and the enclosed IR Remote Control, the optional keyboard or with a USB mouse. They can also be viewed and accessed remotely via the webpages and the ‘Viewer’ menu option.
Page 110 Displays either the default camera selection map or a specific site map (if one has been configured) with ‘hotspots’ showing camera locations. � camera can be viewed by selecting the corresponding hotspot. Purple Ne�t Opens the ne�t page of the �iewer menu. Dedicated Micros ©2008...
Page 111: Video Control
Note: Camera selection via this feature is only temporary. If Quad or Multiscreen view is selected, the camera selected via the Quick Start drop down menu will not be shown in the top left corner of the display. Dedicated Micros ©2008...
Page 112 Press the �u� button followed by the relevant numeric button or via the number bo� displayed on-screen. �lue Prog Opens the Preset programming menu. Refer to ‘PTZ Profile’ menu. Purple Ne�t Opens the ne�t page of the �iewer menu. Dedicated Micros ©2008...
Page 113: Camera Symbols
�hen displayed, use these buttons to zoom in � out of the displayed image or by controlling the camera (depending on mode selected). Note: The above camera symbols will only be displayed if viewing via a local monitor and not via the webpages. Dedicated Micros ©2008...
Page 114 Refer to ‘Console Settings:-Map Config :-Hotspot Origin’ for more information). Note: This option is only available for Oracle dome cameras. Purple �ack ��eturn to the previous page of the �iewer menu. Dedicated Micros ©2008...
Page 115 Cameras are then selected via the hotspots. Refer to ‘Console-Map Config’ for further details on creating Camera Maps. Note: For information on creating System Selection and Camera Selection maps. Refer to the ‘Console-Map Config’ section for further information. Dedicated Micros ©2008...
Page 116: Selection Page
Select this option to exit the Viewer menus. This will be logged in the User Activity Log as the current user terminating the session. Refer to ‘Appendix C’ for further information regarding the User Activity Log. Purple �ack ��eturns to the previous page of the �iewer menu. Dedicated Micros ©2008...
Page 117: Timeline Navigation
Selecting the E�it (Purple) button will always e�it the Timeline Navigation menu. Note: Depending on the scale used to review the video i.e. Seconds, Minutes, Hours, or Days; the above softkey options will differ, however the same intuitive principles remain. Dedicated Micros ©2008...
Page 118: Video Timeline
Date�Time Display. To advance in time, click on the right side of the timeline. Time Scale Options •� 15 seconds •� 1 minute •� 15 minutes •� 1 hour •� 4 hours •� 1 day • 1 week • 4 week Dedicated Micros ©2008...
Page 119: Change Scale
Right Navigation �rrow will play video from one hour in advance. This can also be selected via the ��ellow softkey button. Dedicated Micros ©2008...
Page 120: Event Page
Plays the event and displays the Video Controls toolbar. Green Live Returns to Live video from the currently selected camera. ��ellow Event- Opens the previous event. �lue Event+ Opens the ne�t event. Purple Next �pens the Play menu for the currently displayed event. Dedicated Micros ©2008...
Page 121: Archive Selection Page
Copy Event �ist. ��ellow �rchive Opens the Copy Menu. �lue Seq On�Off Select ‘Seq On’ to display images from all connected cameras in a sequential order. Purple Next �pens the Play menu for the currently displayed camera. Dedicated Micros ©2008...
Page 122: Copy Menu
Displays the space (as a percentage) that will remain following the download. Status Displays messages relevant to the archive process i.e. ‘�rchive In Progress’. Progress Displays the progress of the current archive �as a percentage of completion). Dedicated Micros ©2008...
Page 123 Select CD�D�D from the �rchive Media checkbo�. Select the Copy option (��ed) to start archive. Selected items are then saved to the CD�D�D. The CD�D�D e�port status is displayed as a %. On completion the status will read ‘�rchive Complete’. Dedicated Micros ©2008...
Page 124: Using The Ir Remote Control
The unit can also be controlled using an optional Dedicated Micros keyboard. This is connected via the KBD connector on the rear of the DV-IP Server and provides the same control functions as the I.R Remote Control. The following keyboards are supported: DM/KBC1 Keyboard Dedicated Micros ©2008...
Page 125 Displays the archiving options. �ive mode - No functionality. Play mode - Starts fast forwarding from play time. ��ewind mode - Starts fast forwarding from play time. Pause mode - Steps forward one frame. Dedicated Micros ©2008...
Page 126 Toggles control from Main to Spot monitor. �llows the numeric selection of a camera (numeric selection defaults to camera selection). �llows entry of camera and Preset and numbers. For future use. For future use. Triggers the wash function on a telemetry camera. Dedicated Micros ©2008...
Page 127 Used as menu and on-screen navigation keys Pan and tilt control for telemetry cameras. In Play mode: Used to Mark Start�End positions. ln �ive mode: Displays the Copy �ist and archive controls. E�its menus. Dedicated Micros ©2008...
Page 128: Softkey Guidance
If the D�� is in �ive or Playback mode, pressing the Zoom IN button will Zoom (�2) into the image. Once ‘zoomed in’, it is possible to navigate within the image using the Directional buttons. Directional buttons. . Dedicated Micros ©2008...
Page 129: Appendix A
Receive Data Transmit Data Data Terminal Ready Ground Data Set Ready Ready to Send Clear to Send Ring Indicate RS Connectivity (Serial , ) Description Desc Receive Data Transmit Data Ground Ready to Send Clear to Send Dedicated Micros ©2008...
Page 130: Appendix B
Below are detailed the procedures to follow and a listing of the codes associated with common television brands. How to Program The DV-IP Server IR Remote Control Turn the T� you wish to control ON.
Page 131 8573�604�623�624 �627�629� 635 �636�637�643�644 Pioneer 2029�2037�2081 �2093�2379�2382�2387�2390�2392�2444�2449�2498�2584�2627�26 �2637 Sanyo 2003�2004�2006�2014�2016�2021�2023�2024�2025�2030�2032�2076�2088�2161�22 20�2223�2290�2292�2401�2442�2443�2492�2494�2497�2501�2504�2513�2532�2605� 2627�2629�2633 Sharp 2001�2005�2023�2040�2101�2102�2127�2139�2160�2162�2186�2193�2207�2219�23 35�2352�2354�2360�2365�2366�2368�2372�2373�2376�2403�2407�2417�2422�2423 �2424�2430�2431�2432�2433�2434�2455�2456�2457�2458�2459�2460�2461�2462�24 63�2483�497�502�506�513�533 Sony 2004�2009�2021�2023�2024�2047�2067�2076�2078�2091�2097�2098�2110�21 11�2118�2121�2125�2135 �2142�2166�2177�2185�2204�2234�2236�2326�2344 �2345�2346�2349�2363� 2400�2402�2404�2405�2410 �2413�2418�2420�2439��2493� 2494�2497�2508 �2569�2571�587�602�603�607�639 Technics 2043 Toshiba 2015�2021�2051 �2069�2090�2103�2137�2158�2159�2165�2179�2188�2194 �2208�2211�2213�2217 �2218�2222�2243�2244�2250�2271�2284�2288�2294 �2303 �2304�2313�2318�2319�2320�2321�2322�2328�2347�2350�2370�2375�2394�2409�24 21�2435�2437�2440�2465�466�467�485�487�489�490�496�497�503�508 �526�574�54� 591�595�606�607�632�642 Dedicated Micros ©2008...
Page 132: Appendix C
IP address of user, Local or Remote, Channel Controlled, Command sent Configuration Username, Local or remote, Menus changed, Items changed Playback Username, Remote, Channel viewed, From time Live Username, ��emote, Channel viewed System Events Username, Event Info Dedicated Micros ©2008...
Page 133: Appendix D
None Stop bits Flow Control None Power the unit, the Power �ED on the unit will illuminate. Hyperterminal will display the communications information as the unit boots up. This will include the IP address, Subnet and Gateway. Dedicated Micros ©2008...
Page 134: Appendix E
4�JPEG) across scheduled, normal and alarm modes dynamically on individual cameras. RECORDING FROM Playback and record to hard disk simultaneously. �larmed or manually selected images can be protected from being overwritten. Timed e�piry option allows images to be held for a selected number of days. Dedicated Micros ©2008...
Page 135 �uilt-in ��S485�Twisted pair protocols provide direct control of the numerous domes including but not limited to the following: Coax •� BBV •� BBV RX100 •� Pelco Spectra Serial •� Dedicated Micros �racle Dome • �D Matri��D 168-Matri� •� BBV RE485 StarCard • �osch�Philips G3 • Dennard�Dennard C •� Ernitec • J�C T�-C675�E, T�-C676 & T�-C553E •...
Page 136 DV-IP SERVER DATA Serial Ports: 4 - 2 ��S232 (9 wire) or (3 wire), 2 � ��S232 (3 wire), ��S485. Ethernet: 1� Ethernet ��J-45 10�100 Ethernet connection. US�: 3 � US� 2.0 Connector (1 positioned on the front panel). TEMPERATURE RANGE 5 - 40°C...
Page 141 Data ................10 �uick Camera Selection ..........111 Data ................11 �uick Overview of D�-IP Server ��ecord Settings ..9 Dedicated Micros Managed Storage Expansion units . 20 Record ................. 58 Default DNS Address ........... 21 Record Settings ............57 Dennard 2040 & 2060 Domes ........18 Regulatory Notes and FCC and D�C Information ..
Page 142 Video ................11 Video Control ..............111 VIDE� TIMELINE ............5 Video Timeline............118 �iew Control ............... 110 �iewer Defaults ............44 �MD Configuration ............79 �eb Cam ..............89 Zone Actions ..............72 Zone Input ................ 70 Dedicated Micros ©2008...
Page 144 Dedicated Micros �td. 1200 Daresbury Park, Daresbury, Cheshire, ��4 4HS, U� Dedicated Micros France Dedicated Micros, �ustralia PT��. 9-13 rue du Moulinet 5�3 Packard �venue, Castle Hill, 75013 Paris, France NSW 2154, Australia Dedicated Micros Slovenia Dedicated Micros, �sia PT��...
