Port Status and Configuration
Viewing Port Status and Configuring Port Parameters
Figure 10-14. Example of Displaying the Current MDI Operating Mode
10-22
Figure 10-13. Example of Displaying the Current MDI Configuration
Web: Viewing Port Status and Configuring Port
Parameters
In the web browser interface:
Click on the Configuration tab.
1.
2. Click on
[Port Configuration]
3. Select the ports you want to modify and click on
4. After you make the desired changes, click on
Note that the web browser interface displays an existing port trunk group.
However, to configure a port trunk group, you must use the CLI or the menu
interface. For more on this topic, refer to Chapter 11, "Port Trunking" .
.
[Apply Settings]
Per-Port MDI
Configuration
Per-Port MDI
Operating Mode
.
[Modify Selected Ports]
.
