Introduction

This section contains general information about this guide and the Extron XTP T HDMI
transmitter and XTP R HDMI receiver. Topics in this section include:
•
•
•

About This Guide

This guide contains installation, operation, control, and reference information for the
XTP T HDMI transmitter and the XTP R HDMI receiver.
In this guide, the terms "transmitter," "XTP T HDMI," and "XTP HDMI transmitter" are used
interchangeably to refer to the XTP T HDMI transmitter. The terms "receiver," "XTP R HDMI,"
and "XTP HDMI receiver" are used interchangeably to refer to the XTP R HDMI receiver.

About the XTP HDMI Transmitter and Receiver

Both the XTP T HDMI transmitter and XTP R HDMI receiver send or receive video, audio,
bidirectional RS-232 and IR, and Ethernet over a single twisted pair cable. They are
HDCP-compliant and support 1080p/60 Deep Color and 1920x1200 signals, and
embedded HD lossless audio formats. They work with Extron XTP devices in matrix or
point-to-point applications for signal distribution and long-distance transmission (up to 330
feet) between remote endpoints, using shielded or unshielded CATx cable.
They can be powered locally or remotely through an Extron XTP Power Injector or XTP
matrix switcher.
Both devices can be controlled through Extron Simple Instruction Set (SIS) or the XTP
Configuration Software (see
Configuration Software
About This Guide
About the XTP HDMI Transmitter and Receiver
Key Features
SIS Configuration and Control
on page 23).
XTP T HDMI Transmitter and XTP R HDMI Receiver • Introduction
XTP System
on page 16 or
1
