Audio Output Overview

By default, the XTP HDMI transmitter prioritizes embedded digital audio over analog audio.
Use SIS commands or the XTP System Configuration Software to manually select the audio
input (see
Software
Audio Input Format
LPCM up to 7.1, 24 bit, 192 kHz
Multi-channel PCM
Dolby Digital 2/0
Dolby Digital 2/0 Surround
Dolby Digital 5.1
Dolby Digital EX
Dolby Digital Plus
Dolby TrueHD
DTS 2 Channel
DTS Digital Surround 5.1
DTS-ES Matrix 6.1
DTS-ES Discrete 6.1
DTS-HD
DTS-HD Master Audio
NOTE: The transmitter uses a black signal to simulate a 720p or 1080p, 50 Hz or 60 Hz
signal so audio can be passed without video.

Reset Modes

Use the recessed Reset button on the rear panel of the transmitter or receiver to
return the device to default settings or to restore factory-shipped firmware.
Mode Mode Activation
1 Hold the recessed Reset
button down while applying
power to the device.
NOTE: After a mode 1
reset, update the device
with the latest firmware
version. DO NOT operate
the firmware version that
results from this mode
reset.
SIS Configuration and Control
on page 23).
Reset Mode Summary
Result
The device reverts to the
factory default firmware.
NOTE: If you do not want
to update the firmware or
perform a mode 1 reset
by mistake, cycle power
to the device to return the
firmware version running
prior to the reset.
XTP T HDMI Transmitter and XTP R HDMI Receiver • Installation
on page 16 or the XTP System Configuration
Audio Output
HDMI S/PDIF
X X
X
X X
X X
X X
X X
X
X
X X
X X
X X
X X
X
X
Purpose/Notes
Use mode 1 to roll back to factory
firmware for a single power cycle
if an incompatibility issue arises.
Analog
X
RESET
