- Page 1 User Guide XTP Extenders XTP T HDMI XTP R HDMI XTP HDMI Transmitter and Receiver 68-1723-01 Rev. A 07 13...
- Page 2 Chinese Simplified Safety Instructions • English （简体中文） 警告： 产品上的这个标志意在警告用户该产品机壳内有暴露的危险 WARNING: This symbol, , when used on the product, is intended to alert the user of the presence of uninsulated dangerous voltage 电压， 有触电危险。 within the product’s enclosure that may present a risk of electric shock.
- Page 3 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 Conventions Used in this Guide Notifications The following notifications are used in this guide: A warning indicates a situation that has the potential to result in death or WARNING: severe injury. ATTENTION: Attention indicates a situation that may damage or destroy the product or associated equipment.
-
Page 5: Table Of Contents
Installing Firmware with Firmware Loader ..32 SIS Programming Guide ........16 Host-to-Device and Device-to-Host Communication ........... 16 Error Responses ........... 17 Using the Command and Response Table for SIS Commands ........17 XTP T HDMI Transmitter and XTP R HDMI Receiver • Contents... - Page 6 XTP T HDMI Transmitter and XTP R HDMI Receiver • Contents...
-
Page 7: Introduction
“XTP HDMI receiver” are used interchangeably to refer to the XTP R HDMI receiver. About the XTP HDMI Transmitter and Receiver Both the XTP T HDMI transmitter and XTP R HDMI receiver send or receive video, audio, bidirectional RS-232 and IR, and Ethernet over a single twisted pair cable. They are HDCP-compliant and support 1080p/60 Deep Color and 1920x1200 signals, and embedded HD lossless audio formats. -
Page 8: Key Features
The following diagram shows some ways the XTP T HDMI and the XTP R HDMI can be integrated in an XTP matrix application. Ethernet Extron AV Control TLP 1000TV Network 10" Tabletop TouchLink Ethernet Touchpanel Extron IPCP 505 IP Link Control... - Page 9 Receiver HDMI audio de-embedding with analog stereo and digital S/PDIF audio outputs — Digital HDMI audio is made available as a balanced or unbalanced analog stereo signal on captive screw connectors or a S/PDIF connector. XTP T HDMI Transmitter and XTP R HDMI Receiver • Introduction...
-
Page 10: Installation And Operation
Installation and Operation This section contains the installation procedures for and operation of the XTP T HDMI and the XTP R HDMI. Topics in this section include: Cabling • • Making Connections • Operation XTP HDMI transmitters and receivers can be mounted in a rack or under a desk or placed... - Page 11 2-pole captive screw connector. The Power LED lights to indicate the device is receiving power. NOTE: XTP HDMI transmitters and receivers can also be powered remotely (see Power Connection on page 11). XTP T HDMI Transmitter and XTP R HDMI Receiver • Installation...
-
Page 12: Xtp R Hdmi Rear Panel Connectors
Use Extron LockIt lacing brackets to secure HDMI connectors to the device (see HDMI LockIt on page 8). • Video input from a DisplayPort source must be a dual mode DisplayPort source. XTP T HDMI Transmitter and XTP R HDMI Receiver • Installation... -
Page 13: Front Panel Configuration Port
Front Panel Configuration Port Front Panel Config Port — Connect a host device to the female mini-USB B port to configure the connected transmitter or receiver or update firmware. XTP T HDMI Transmitter and XTP R HDMI Receiver • Installation... -
Page 14: Making Connections
Loosely place the included tie wrap around the HDMI connector and the LockIt lacing bracket (see figure 7). While holding the connector securely against the lacing bracket, use pliers or similar tools to tighten the tie wrap, then remove any excess length. XTP T HDMI Transmitter and XTP R HDMI Receiver • Installation... -
Page 15: Tp Cable Termination And Recommendations
Connector Figure 8. TP Cable Termination Supported cables The XTP T HDMI and XTP R HDMI are compatible with CAT 5e, 6, 6a, and 7 shielded twisted pair (F/UTP, SF/UTP, and S/FTP) and unshielded twisted pair (U/UTP) cable. ATTENTION: •... -
Page 16: Rs-232 And Ir Communication
The length of exposed wires is critical. The ideal length is 3/16 inch (5 mm). • Longer bare wires can short together • Shorter wires are not as secure in the connectors and could be pulled out. XTP T HDMI Transmitter and XTP R HDMI Receiver • Installation... -
Page 17: Power Connection
Figure 10. Power Wiring Both the XTP T HDMI and the XTP R HDMI can be connected to a local power supply. WARNING: Electric shock hazard. The two power cord wires must be kept separate while the power supply is plugged in. Remove power before wiring. -
Page 18: Remote Power
XTP endpoints (refer to the user guide of the XTP matrix switcher for more details). To manage available power from the XTP matrix switcher, use the XTP System Configuration Software (see XTP System Configuration Software on page 23). XTP T HDMI Transmitter and XTP R HDMI Receiver • Installation... -
Page 19: Operation
XTP indicators Signal LED — Lights when an active XTP input signal is received. HDCP LED — Lights when the input signal is encrypted. XTP T HDMI Transmitter and XTP R HDMI Receiver • Installation... -
Page 20: Hdmi Audio Switch
NOTE: switcher using the XTP System Configuration Software. The XTP T HDMI can record and save EDID in a user memory location on the transmitter. EDID can come from the loop-through display on the transmitter or the output display on the receiver (default). -
Page 21: Audio Output Overview
DO NOT operate by mistake, cycle power the firmware version that to the device to return the results from this mode firmware version running reset. prior to the reset. XTP T HDMI Transmitter and XTP R HDMI Receiver • Installation... -
Page 22: Sis Configuration And Control
SIS commands consist of one or more characters per field. No special characters are required to begin or end a command sequence. When the XTP T HDMI or the XTP R HDMI determines that a command is valid, it executes the command and sends a response to the host device. -
Page 23: Error Responses
Error Responses When the XTP T HDMI or the XTP R HDMI receives an SIS command and determines that it is valid, it performs the command and sends the corresponding response to the host device. If the command is determined invalid or contains invalid parameters, the transmitter or receiver returns an error response to the host. - Page 24 1440x900 1600x1200 1680x1050 1920x1080 with 2-ch audio HDMI 1920x1200 800x600 1024x768 1280x720 with 2-ch audio HDMI 1280x768 1280x800 1280x1024 1360x768 1366x768 1400x1050 1440x900 * = default XTP T HDMI Transmitter and XTP R HDMI Receiver • SIS Configuration and Control...
-
Page 25: Command And Response Tables For Transmitter Sis Commands
Command and Response Tables for Transmitter SIS Commands The following commands are for direct connections to the XTP T HDMI (see to the XTP matrix switcher user guide for commands that can be sent from the matrix to endpoints). Command... -
Page 26: Edid
= video or TMDS signal not detected = video or TMDS signal detected = HDCP authorized device status = off = on (default) table = EDID emulation See the on page 18. XTP T HDMI Transmitter and XTP R HDMI Receiver • SIS Configuration and Control... -
Page 27: Command And Response Tables For Receiver Sis Commands
= Audio mute = unmute all = mute all = Relay number = relay 1 = relay 2 = Pulse time (in 16 ms increments) 1-65,535 XTP T HDMI Transmitter and XTP R HDMI Receiver • SIS Configuration and Control... - Page 28 = display connected and not currently encrypted = display connected and currently encrypted = Video signal status = video or TMDS signal not detected = video or TMDS signal detected XTP T HDMI Transmitter and XTP R HDMI Receiver • SIS Configuration and Control...
-
Page 29: Xtp System Configuration Software
Follow the instructions that appear on the screen. By default, the installation creates an Extron directory in the Program Files folder, and places four icons into a group folder named “Extron Electronics\XTP System Configuration.” XTP T HDMI Transmitter and XTP R HDMI Receiver • XTP System Configuration Software... -
Page 30: Using The Xtp System Configuration Software
7). From the Connections screen, select the radio button. Select the connected device to be controlled from the displayed list. Click the button. Connect XTP T HDMI Transmitter and XTP R HDMI Receiver • XTP System Configuration Software... -
Page 31: Transmitter Configuration
This is not selected by default. If enabled, select the black signal resolution from the drop-down list. The Signal Type default resolution is 720p @ 60 Hz. XTP T HDMI Transmitter and XTP R HDMI Receiver • XTP System Configuration Software... - Page 32 Select the check box of the connected input to the right of the Available EDID pane. Click the button below the input area. Assign TIP: Alternatively, EDID can be assigned by dragging and dropping the desired EDID onto the input. XTP T HDMI Transmitter and XTP R HDMI Receiver • XTP System Configuration Software...
- Page 33 EDID settings common among Timings the selected outputs. Select the desired common EDID setting. The EDID setting will be shown in the Available EDID pane. XTP T HDMI Transmitter and XTP R HDMI Receiver • XTP System Configuration Software...
-
Page 34: Receiver Configuration
Factory reset Click the button to reset the receiver to factory settings except for Factory Reset firmware. NOTE: This is the same as the SIS command. ZXXX XTP T HDMI Transmitter and XTP R HDMI Receiver • XTP System Configuration Software... -
Page 35: Reference Information
• Updating Firmware with Firmware Loader Mounting The XTP T HDMI and the XTP R HDMI can be placed on a tabletop or mounted in a rack or underneath a desk. Tabletop Mounting Attach the provided rubber feet to the bottom four corners of the enclosure. -
Page 36: Updating Firmware With Firmware Loader
Updating Firmware with Firmware Loader To upload and update firmware for the XTP T HDMI and XTP R HDMI, download the new firmware to a connected computer and upload the firmware with the Firmware Loader utility. Downloading Extron Firmware Loader Figure 19. -
Page 37: Downloading Firmware
A Release Notes file, giving information on what has changed in the new firmware version, and a set of instructions for updating the firmware are also loaded. XTP T HDMI Transmitter and XTP R HDMI Receiver • Reference Information... -
Page 38: Installing Firmware With Firmware Loader
Begin Close Firmware Loader when the field shows , the Remaining Time 00.00.00 column is , and the field is Progress 100% Status completed XTP T HDMI Transmitter and XTP R HDMI Receiver • Reference Information... - Page 39 Extron Warranty Extron Electronics warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components, to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is returned within the warranty period, with proof of purchase and description of malfunction to: USA, Canada, South America,...
